ABB NTAC-02 58967441E DCS PLC Module

Product Name:

ABB NTAC-02 58967441E – DCS PLC Module (Network Terminal Access Controller)

Product Description:

The ABB NTAC-02 58967441E is a specialized DCS PLC module used in the ABB 800xA Distributed Control System. This module serves as a Network Terminal Access Controller (NTAC), designed to interface between the field devices, control systems, and supervisory layers within the process automation environment. It facilitates secure and high-performance communication across various networks while ensuring reliable data transfer and control for process automation. This module is part of ABB’s broader offering of automation systems aimed at enhancing operational efficiency, process safety, and system scalability.

It is suitable for industries like oil and gas, chemical processing, power generation, and manufacturing, where robust and real-time communication between control systems and field devices is crucial for the safe and efficient operation of complex processes.

Product Parameters:

• Model: NTAC-02 58967441E

• Type: Network Terminal Access Controller (NTAC) Module

• System Compatibility: Part of ABB 800xA Distributed Control System

• Form Factor: Typically rack-mounted in standard DCS modules

• Power Supply:

  • 24V DC (nominal)
  • Power consumption: ~15-20W (varies depending on configuration)

• Operating Temperature:

  • Standard: -40°C to 70°C
  • Storage Temperature: -40°C to 85°C

• Relative Humidity: 5% to 95% (non-condensing)

• Dimensions:

  • Typically 4.5″ x 8.5″ x 2″ (varies depending on configuration)

• Weight: ~0.4 kg

Key Specifications:

• Processor:

  • High-performance processor designed to handle high-speed, real-time communication and control in automation systems.
  • Dual-core processor architecture for increased processing capability.

• Memory:

  • RAM: 512MB to 1GB, depending on configuration
  • Flash Memory: 2GB to 4GB for system storage, logs, and configurations
  • Expandable Memory: Modular expansion options for higher memory requirements.

• Communication Protocols:

  • Ethernet: Gigabit Ethernet ports (1 or 2) for high-speed communication and data transfer.
  • Modbus TCP/IP: Supports integration with various field devices and other controllers.
  • PROFIBUS: Supports integration with PROFIBUS field devices for industrial automation.
  • Modbus RTU: Compatible with Modbus RTU for communication with legacy devices.
  • HART: Supports communication with HART-enabled field instruments.
  • IEC 61850: For integration with IEC 61850-based substations in power utilities.
  • Redundant Ethernet: Supports network redundancy for enhanced reliability and availability.

• I/O Capability:

  • Digital I/O: Typically configurable up to 32 digital inputs and outputs per module (depending on the specific setup).
  • Analog I/O: Configurable up to 16 analog inputs and 8 analog outputs per module.
  • Fieldbus I/O: Supports communication via PROFIBUS, Modbus, Foundation Fieldbus, and other fieldbus protocols for enhanced connectivity.
  • Expandable I/O: The system allows for easy expansion via additional modules, supporting diverse field device configurations.

• Control Functions:

  • Real-time Control: Supports the execution of control strategies like PID, fuzzy logic, and batch control directly in the module.
  • Redundant Control: Supports redundancy in control functions to ensure high availability in mission-critical processes.
  • Fault Tolerant: Real-time diagnostics and automatic failover mechanisms ensure the system remains operational during faults.

• Safety Features:

  • SIL 2/3 Compliance: Designed to meet Safety Integrity Level (SIL) 2/3, ensuring high safety standards for critical processes.
  • Fail-Safe Operation: Designed for continuous operation with fail-safe mechanisms for protecting processes and reducing downtime.
  • Emergency Shutdown (ESD): Supports emergency shutdown systems in case of dangerous situations.

• Diagnostics and Monitoring:

  • Built-in Diagnostics: Includes self-diagnostics and status monitoring features for detecting failures early and preventing disruptions.
  • Event Logging: Captures and logs significant events for troubleshooting and system analysis.
  • Predictive Maintenance: The module supports predictive maintenance strategies, allowing operators to foresee potential failures and minimize downtime.
  • Real-time Fault Detection: Detects and isolates faults within the system to maintain continuous operation.

• User Interface:

  • ABB 800xA HMI Integration: Fully integrated with the ABB 800xA Human-Machine Interface (HMI), providing operators with intuitive monitoring and control capabilities.
  • Web Access: Remote configuration and diagnostics through web-based interfaces.
  • Alarm Management: Includes integrated alarm handling to alert operators of system malfunctions or abnormal conditions.

Key Features and Advantages:

1. High-Performance Networking:

   • Provides high-speed communication between various subsystems and devices through Ethernet and PROFIBUS protocols, ensuring efficient data transfer and real-time control.

2. Redundant Communication and Control:

   • Designed to ensure continuous operation with network and controller redundancy for high-availability applications in mission-critical systems.

3. Seamless Integration:

   • Fully integrated within the ABB 800xA system, making it ideal for large, complex industrial applications where multiple controllers and field devices need to be coordinated.

4. Advanced Diagnostics and Predictive Maintenance:

   • Built-in diagnostics and predictive maintenance capabilities ensure early fault detection and reduce system downtime.

5. Safety Compliance:

   • Complies with SIL 2/3 standards, ensuring the module can be used in safety-critical environments such as oil & gas refineries, power plants, and chemical factories.

6. Modular and Scalable:

   • The NTAC-02 module offers flexible expansion options, making it scalable to meet the changing needs of industrial operations.

7. Efficient Resource Management:

   • By enabling central management and control, it helps in optimizing resource allocation and improving system efficiency.

Applications:

The ABB NTAC-02 58967441E is commonly used in industries that require secure and fast communication and control, such as:

• Power Generation: Integration with control systems for turbines, generators, and substations.
• Oil & Gas: Provides control and monitoring of upstream, midstream, and downstream operations.
• Chemical & Petrochemical: Used in managing complex chemical reactions, batch production, and refining processes.
• Water Treatment: Monitoring and control of pumps, filtration, and distribution systems.
• Manufacturing: Supports automation in various sectors including automotive, steel production, and food processing.

Competitive Comparison:

In comparison to other DCS modules from manufacturers such as Siemens or Honeywell, the ABB NTAC-02 module stands out due to:

• Superior Networking: High-speed Ethernet communication and wide protocol compatibility for seamless integration.
• Redundancy Features: Offers full redundancy in both control and communication, ensuring higher system uptime.
• SIL 2/3 Safety Compliance: Suitable for safety-critical environments with SIL compliance for critical processes.
• Easy Integration: Works flawlessly with ABB’s 800xA platform, simplifying configuration and deployment.

The ABB NTAC-02 58967441E DCS PLC module is a versatile, high-performance component designed to meet the demanding needs of industrial automation systems. With its robust communication capabilities, real-time control, and diagnostic features, it plays a crucial role in ensuring operational efficiency, safety, and scalability in large-scale industrial processes.
