FBM202 Thermocouple/mV Input Module (P0916AC):
- This is an 8-channel isolated input module designed to interface with thermocouples and millivolt (mV) signals. It’s used to measure temperature in industrial processes.
- Key Features:
- 8 isolated input channels for thermocouple or mV signals.
- One isolated RTD (Resistance Temperature Detector) channel for reference junction compensation.
- Supports standard thermocouples for various temperature ranges.
- Thermocouple burnout detection.
- Galvanic isolation between channels and from ground.
- High accuracy due to sigma-delta data conversion.
- Technical Specifications (Typical):
- Input Range: -10.5 to +69.5 mV DC.
- RTD Reference Junction Conformity: ±0.25°C.
- Accuracy (mV Input): ±0.03% of span.
- Operating Voltage: 24 VDC.
- Applications: It’s used in industries requiring precise temperature measurements, such as power generation, chemical processing, and pharmaceuticals.
-
Compression Terminal Assembly (P0916AC):
- This is a terminal block designed for connecting pneumatic transmitters to process piping. It ensures a reliable connection in harsh environments.
- Key Features:
- Made of stainless steel for durability.
- Easy installation and removal.
- Compatible with a wide range of pneumatic transmitters.
- Technical Specifications (Typical):
- Material: Stainless steel.
- Connection Size: 1/2″ NPT.
- Pressure Range: Up to 3000 psi (20.7 MPa).
- Temperature Range: -40 to 121°C.
It is important to note the FBM202 module often uses the P0916AC terminal block.
