The GE DS200PANAH2A is an ARCNET Interface Card for the UC2000 Unit Controller series. This board acts as a crucial communication component, enabling the controller to send and receive data over an ARCNET industrial network. The AH2A designation represents a specific hardware revision of this board, which may include minor component updates or improvements over earlier versions.
Technical Breakdown 🧠
The card’s function is foundational to the system’s communication architecture:
- ARCNET Communication: The primary function of this card is to provide the physical and logical interface for the controller to communicate via the ARCNET (Attached Resource Computer Network) protocol. ARCNET is a token-passing network protocol known for its deterministic, real-time performance, which is a key requirement in industrial automation. Its token-passing architecture ensures that every node on the network gets a turn to transmit, eliminating data collisions and guaranteeing timely data delivery, making it ideal for critical control applications.
- Interface Functionality: The card handles all the necessary functions for reliable network communication, including data packet framing, error detection, and the management of the physical layer. It provides the UC2000 with the ability to exchange data with other controllers, human-machine interfaces (HMIs), and supervisory control systems within a plant.
- UC2000 Context: The UC2000 is a highly capable unit controller designed for a variety of industrial processes. The DS200PANAH2A is a specific I/O option that gives it the networking flexibility to be integrated into a larger, distributed control system, allowing for seamless data sharing and coordinated control across different units.
In essence, the DS200PANAH2A is the essential gateway that allows the controller to be part of a larger, interconnected automation system, enabling centralized monitoring and control.
Applications 🏭
The GE DS200PANAH2A is a critical component in the communication infrastructure of control systems in:
- Power Plants: For connecting turbine controllers and exciters to a plant-wide control network.
- Oil & Gas: For remote monitoring and control of pipelines and pumping stations.
- Manufacturing: For data exchange and synchronization between different production units.
