GE DS2020FEANRX075A Field Exciter Module

GE DS2020FEANRX075A Field Exciter Module

GE DS2020FEANRX075A Field Exciter Module is a 75 Amp capacity power electronic assembly used in General Electric Mark V Turbine Control Systems and related industrial drive panels.1

⚡ Primary Function: Field Excitation Control

This module’s core purpose is to provide precise regulation of the $\text{DC}$ current supplied to the field winding of a large synchronous generator or motor.

  • Excitation Management: It acts as a controlled 2$\text{DC}$ power source, managing the current that generates the magnetic field in the rotating machinery.3
  • Voltage and Stability: By precisely controlling this excitation current, the module regulates the machine’s output voltage and reactive power (4$\text{VAr}$), which is critical for ensuring grid stability in power generation applications.5
  • Application: It is a key component within the $\text{DS}2020$ family of modular assemblies, widely used in the control systems for gas and steam turbines.
احصل على عرض أسعار
التصنيف:

الوصف

The GE DS2020FEANRX075A Field Exciter Module is a 75 Amp capacity power electronic assembly used in General Electric Mark V Turbine Control Systems and related industrial drive panels.1

⚡ Primary Function: Field Excitation Control

This module’s core purpose is to provide precise regulation of the $\text{DC}$ current supplied to the field winding of a large synchronous generator or motor.

  • Excitation Management: It acts as a controlled 2$\text{DC}$ power source, managing the current that generates the magnetic field in the rotating machinery.3
  • Voltage and Stability: By precisely controlling this excitation current, the module regulates the machine’s output voltage and reactive power (4$\text{VAr}$), which is critical for ensuring grid stability in power generation applications.5
  • Application: It is a key component within the $\text{DS}2020$ family of modular assemblies, widely used in the control systems for gas and steam turbines.

⚙️ Key Technical Details

The part number provides the essential specifications for this module:

Feature Specification / Description
Product Series GE Mark V Turbine Control System (DS2020 Family)
Functional Name Field Exciter Module
Current Rating $\mathbf{75 \text{ Amps DC}}$ (Maximum excitation current)
Field Supply Style NRX (Non-Reversing/Non-Plugging) compatible
Input Power Typically $\text{Single-Phase, } 600 \text{ V AC}$ at $\text{50/60 Hz}$
Output Voltage Typical $\text{DC}$ output is up to $\mathbf{500 \text{ V DC}}$
Physical Design Robust, modular metallic chassis, often featuring an integrated cooling fan.

The designation FEANRX stands for Field Exciter Assembly Non-reversing, with the $\text{RX}$ suggesting a specific $\text{PCB}$ coating or protection feature. The 6$\mathbf{075\text{A}}$ clearly identifies its maximum current capability.7
