GE DS215DMCAG2AZZ02A DOS Main Control Board

GE DS215DMCAG2AZZ02A DOS Main Control Board

د.إ8,888.00

GE DS215DMCAG2AZZ02A is a critical, highly-integrated printed circuit board assembly used in General Electric’s industrial control systems, most famously the Speedtronic Mark V Turbine Control System.

The designation “DOS Main Control Board” often refers to its role as a key logic and interface component that manages system functions and interacts with the control environment.

⚙️ Key Specifications and Function

Feature Specification/Description
Product Type Drive Main Control Assembly (DMCA) / Processor Interface Board
Series/Family GE Speedtronic Mark V Turbine Control Systems and Industrial Drives (e.g., DC2000)
Core Function Logic and Interface Management. This board acts as a vital link between the main control processor (like the UCOM board) and several key subsystems, including: * Operator Interface: Handles data flow from the local keypad/display (HMI). * Data Logging: Manages and buffers data for event and fault history. * Control Logic: Executes critical low-level or specialized logic within the drive/turbine control framework.
Architecture It is a module that plugs into the VME rack of the Mark V system, where it manages communication and control of various peripherals and local I/O.
Firmware Role The suffix AZZ02A is highly significant, indicating that the board is pre-loaded with a specific firmware/software package. This specific firmware defines the board’s exact operational logic and compatibility with the overall system control program.
احصل على عرض أسعار
التصنيف:

الوصف

GE DS215DMCAG2AZZ02A DOS Main Control Board

The GE DS215DMCAG2AZZ02A is a critical, highly-integrated printed circuit board assembly used in General Electric’s industrial control systems, most famously the Speedtronic Mark V Turbine Control System.

The designation “DOS Main Control Board” often refers to its role as a key logic and interface component that manages system functions and interacts with the control environment.

⚙️ Key Specifications and Function

Feature Specification/Description
Product Type Drive Main Control Assembly (DMCA) / Processor Interface Board
Series/Family GE Speedtronic Mark V Turbine Control Systems and Industrial Drives (e.g., DC2000)
Core Function Logic and Interface Management. This board acts as a vital link between the main control processor (like the UCOM board) and several key subsystems, including: * Operator Interface: Handles data flow from the local keypad/display (HMI). * Data Logging: Manages and buffers data for event and fault history. * Control Logic: Executes critical low-level or specialized logic within the drive/turbine control framework.
Architecture It is a module that plugs into the VME rack of the Mark V system, where it manages communication and control of various peripherals and local I/O.
Firmware Role The suffix AZZ02A is highly significant, indicating that the board is pre-loaded with a specific firmware/software package. This specific firmware defines the board’s exact operational logic and compatibility with the overall system control program.
Revision Level The G2 specifies the Group 2 hardware revision, indicating an update or change from earlier Group 1 (G1) versions of the same DMCA board, likely involving component changes or minor layout modifications.

In short, the DS215DMCAG2AZZ02A is a fundamental piece of the Mark V’s modular system, dedicated to handling the interface, diagnostics, and essential logic required to ensure reliable control and monitoring of a gas or steam turbine.
