GE DS3800NTBL/RR D Bus Terminator
Brief Product Description
The GE DS3800NTBL/RR (D Bus Terminator) is an electronic circuit board used in industrial control systems to properly terminate a data bus. In a networked system, a terminator is crucial for preventing signal reflections, which can cause data corruption and communication errors. This module ensures the integrity of the data signals traveling along the “D” bus, which is a key communication channel in the GE control system.
Key Specifications:
- Type: Data Bus Terminator
- Part Number: DS3800NTBL/RR
- Compatibility: GE industrial drive and control systems
- Function: Prevents signal reflections on a data bus
- Application: Industrial automation, network communication
Detailed Product Overview
In a digital communication network, signals travel as electrical pulses. When a pulse reaches the end of a long wire or bus, it can “bounce back” if the line isn’t properly terminated. This reflected pulse interferes with new signals, leading to data loss, intermittent errors, and unreliable system performance. The GE DS3800NTBL/RR is designed to solve this problem. It acts as a “signal sponge,” absorbing the electrical pulses at the end of the D bus and preventing them from reflecting back. This ensures that the data being transmitted is clean and accurate, which is essential for a stable and responsive control system.
The “RR” in the part number indicates that the unit is a remanufactured part. This is a common and cost-effective practice for maintaining legacy industrial systems. Remanufactured parts are inspected, repaired, and tested to meet original specifications, offering a reliable alternative to new components at a lower cost.
Technical Specifications
Key Features and Benefits
- Ensures Data Integrity: By preventing signal reflections, the terminator ensures that communication on the data bus is reliable and error-free, which is crucial for a control system’s performance.
- Cost-Effective Maintenance: As a remanufactured unit, it offers a more affordable solution for repair and maintenance, helping to extend the operational life of existing equipment.
- Simplified Troubleshooting: A properly terminated bus is easier to diagnose, as it eliminates a common source of intermittent communication issues.
Primary Applications
The GE DS3800NTBL/RR is an essential component in any industrial application that uses a networked GE control system. It is found in a variety of settings where reliable communication is paramount, including:
- Steel and Paper Mills: For coordinated control of large machinery.
- Power Generation Plants: For managing communication between turbine control modules.
- Heavy Manufacturing: In complex assembly lines and automated processes.
Related Products
When working with the GE DS3800NTBL/RR D Bus Terminator, you may also be familiar with these related components:
- GE DS3800HCMB/RR: A Universal Communications Processor that relies on a properly terminated bus to function correctly.
- Rockwell ICS T8151B: A triple-redundant processor module that highlights the industry’s focus on fail-safe designs.
- Siemens C98043-A7001-L1-2: A gate driver card for Siemens drives.
- Honeywell TDC 3000: A distributed control system that uses various I/O and processing cards, all of which depend on a stable communication network.
