GE IC695PBM300 RX3i PROFIBUS Master Module

GE IC695PBM300 RX3i PROFIBUS Master Module

  • PROFIBUS-DP Master: The module acts as the “master” on a PROFIBUS-DP network, which is a high-speed fieldbus commonly used in industrial automation. It controls the data exchange with up to 125 slave devices (e.g., remote I/O blocks, sensors, drives).
  • Data Exchange: It supports a significant amount of data, with a maximum of 3,584 bytes of input data and 3,584 bytes of output data for the entire network. For each individual slave, it supports up to 244 bytes of input and 244 bytes of output data.
  • Standard Data Rates: The module supports all standard PROFIBUS data rates, ranging from 9.6 kBit/s up to 12 MBit/s, providing flexibility for different network configurations.
  • Advanced Features: The IC695PBM300 includes support for advanced PROFIBUS functions like Sync and Freeze modes, which allow for synchronized data acquisition and output among all slaves. It also supports DP-V1 Read, Write, and Alarm messages.
  • Diagnostics: The module provides detailed diagnostic information, including a Slave Status Bit Array, network diagnostic counters, and module status LEDs to simplify network monitoring and troubleshooting.
  • Software Configuration: The module is configured using the Proficy Machine Edition software and requires a host RX3i CPU with firmware version 2.9 or later.
  • Hot Swap Capability: Like other RX3i modules, it supports hot insertion and extraction, allowing for replacement while the system is powered on, which minimizes downtime.
احصل على عرض أسعار
التصنيف:

الوصف

The GE IC695PBM300 is a PROFIBUS Master Module for the PACSystems RX3i series of Programmable Logic Controllers (PLCs). Its main purpose is to allow the RX3i CPU to communicate with and control devices on a PROFIBUS-DP network.



Key Features and Specifications



  • PROFIBUS-DP Master: The module acts as the “master” on a PROFIBUS-DP network, which is a high-speed fieldbus commonly used in industrial automation. It controls the data exchange with up to 125 slave devices (e.g., remote I/O blocks, sensors, drives).
  • Data Exchange: It supports a significant amount of data, with a maximum of 3,584 bytes of input data and 3,584 bytes of output data for the entire network. For each individual slave, it supports up to 244 bytes of input and 244 bytes of output data.
  • Standard Data Rates: The module supports all standard PROFIBUS data rates, ranging from 9.6 kBit/s up to 12 MBit/s, providing flexibility for different network configurations.
  • Advanced Features: The IC695PBM300 includes support for advanced PROFIBUS functions like Sync and Freeze modes, which allow for synchronized data acquisition and output among all slaves. It also supports DP-V1 Read, Write, and Alarm messages.
  • Diagnostics: The module provides detailed diagnostic information, including a Slave Status Bit Array, network diagnostic counters, and module status LEDs to simplify network monitoring and troubleshooting.
  • Software Configuration: The module is configured using the Proficy Machine Edition software and requires a host RX3i CPU with firmware version 2.9 or later.
  • Hot Swap Capability: Like other RX3i modules, it supports hot insertion and extraction, allowing for replacement while the system is powered on, which minimizes downtime.
