Product Name:
GE DS200RTBAG2AFB PLC Module
Product Description:
The GE DS200RTBAG2AFB is a Relay Terminal Board module that is part of the GE Mark V and Mark VIe control systems, designed primarily for use in industrial automation, specifically within power generation, chemical processing, oil & gas, and other heavy industrial sectors. This module serves as an interface between relay outputs and the field wiring, enabling the safe and reliable transmission of control signals between the PLC or control system and external devices.
The DS200RTBAG2AFB is designed to support high-speed relay control applications and provides a robust method for distributing control signals to actuators, alarms, and other relay-controlled devices in complex industrial environments. It also offers feedback and status monitoring, ensuring that operators can detect faults or abnormal conditions in the control system quickly and efficiently. The module is part of the broader GE Mark V or Mark VIe series, designed for high-reliability applications in mission-critical systems.
Product Parameters:
- Module Type: Relay Terminal Board (RTB)
- Compatible Control System: GE Mark V or Mark VIe
- Application: Industrial relay control and feedback in process control systems
- Relay Type: Form C relay outputs, typically for alarm or control signals
- Primary Function: Acts as an interface between relay outputs of the control system and field wiring
- Field Connections: Terminals for wiring control circuits to external devices (e.g., actuators, motors, alarms)
- Diagnostics: Provides diagnostic feedback for relay health and wiring status
- Mounting: Typically mounted in a control cabinet as part of the distributed control system
- Environmental Conditions: Designed for harsh industrial environments
- Operating Temperature Range: -20°C to +70°C (depending on specific configuration)
- Power Supply: Typically 24V DC for control and communication circuits
Product Specifications:
| Specification | Details |
|---|---|
| Model Number | DS200RTBAG2AFB |
| Brand | General Electric (GE) |
| Control System Compatibility | GE Mark V and Mark VIe Control Systems |
| Module Type | Relay Terminal Board (RTB) |
| Relay Type | Form C relay outputs (SPDT – Single Pole Double Throw) |
| Primary Application | Interface for relay outputs and field wiring in industrial automation systems |
| Field Wiring | Provides terminal connections for wiring to external devices (motors, actuators, alarms, etc.) |
| Power Supply | Typically 24V DC |
| Operating Temperature Range | -20°C to +70°C |
| Mounting Type | Typically mounted in control cabinets or as part of a distributed control system |
| Terminal Type | Screw terminal connections for wiring |
| Number of Relays | Typically supports up to 12 relays (depends on the configuration) |
| Diagnostic Feedback | Provides real-time feedback on relay status, enabling fault detection and system monitoring |
| Relay Output Rating | Typically rated for 24V DC or 120V AC signals for actuator control |
| Environmental Protection | Built to withstand industrial conditions (vibration, EMI, high temperatures) |
| Relay Contacts Rating | 5A at 250V AC or 30V DC |
| Isolation | Offers optical isolation between the control system and the field wiring for protection against electrical noise |
Key Features:
-
Relay Control Interface: The DS200RTBAG2AFB is designed to interface between the relay outputs of a GE control system and external field devices, such as actuators, alarms, and other relay-controlled equipment.
-
Feedback and Diagnostics: It provides real-time feedback on the health and status of the relays, allowing operators to monitor the health of the control signals and wiring.
-
Form C Relay Contacts: The module typically includes Form C relays, allowing for both Normally Open (NO) and Normally Closed (NC) contact configurations, offering flexibility in control applications.
-
High Reliability: Designed to operate in harsh industrial environments with high electromagnetic interference (EMI), vibration, and temperature fluctuations, the module is built to provide continuous, reliable performance.
-
Modular Design: The module is part of the modular GE Mark V/VIe system, making it easy to integrate into a larger control system while
