GE+DS3800NB1F1B1A

الوصف

Product Name:

GE DS3800NB1F1B1A PLC Module

Product Description:

The GE DS3800NB1F1B1A is a part of the GE Fanuc Series 5000 PLC systems, designed for use in industrial automation. This module is a Relay Output Board (also known as a “Contact Output Module”) that allows for reliable switching of external devices based on control system commands. It’s typically used to interface with external actuators such as motors, lights, or other heavy-duty machinery that require a relay-based switching operation.

The DS3800NB1F1B1A PLC module supports contact output capabilities and is designed to work in demanding industrial environments. It features high durability, ease of integration with other control systems, and reliable performance in both low and high-stress operational settings. This output module can be found in applications ranging from factory automation to process control systems.

Product Parameters:

• Module Type: Relay Output Board (Contact Output)
• Control System Compatibility: GE Fanuc Series 5000 PLC (often used with Series 90-30 or VersaMax PLCs)
• Output Type: Relay contacts (dry or volt-free contact)
• Relay Rating: Supports high-voltage or high-current switching (depends on relay specifications)
• Power Supply: Typically powered by 24V DC from the PLC backplane
• Number of Channels: The specific number of output channels can vary depending on the module’s configuration
• Environmental Compatibility: Designed for industrial environments with varying temperature ranges and operational conditions
• Mounting Type: Typically installed within the PLC rack or control panel

Product Specifications:

Key Features:

1. Relay Contact Outputs: The DS3800NB1F1B1A provides volt-free relay contact outputs, making it suitable for controlling a wide range of external devices that require switching, such as lights, motors, or other actuators.

2. High Current and Voltage Switching: The module can handle higher current and voltage levels, making it useful for applications that require substantial power switching.

3. Easy Integration: It is designed to easily integrate with the GE Fanuc Series 5000 PLC systems and also with other GE systems such as the Series 90-30 and VersaMax PLC series. This feature makes it versatile in various automation environments.

4. Industrial Durability: Built to perform reliably in harsh industrial environments, the module can withstand a range of environmental factors, including temperature fluctuations, vibration, and electromagnetic interference (EMI).

5. Diagnostic Feedback: It provides diagnostic feedback for troubleshooting and system health, helping operators monitor the relay output status in real-time.

6. Energy Efficiency: Operates with 24V DC power, which is typical for industrial control systems, ensuring low power consumption.

7. Modular Design: The modular nature of the PLC allows for easy configuration and scaling of systems depending on the number of outputs required.

Applications:

• Factory Automation: Ideal for controlling motors, actuators, and other devices in manufacturing and production lines.
• Process Control Systems: Used to manage external equipment like pumps, valves, and other machinery in industrial process systems.
• Machine Control: Suitable for controlling complex machinery in automated systems, where relay outputs are necessary for high-power control.
• Remote Control Systems: Can be used in remote control environments where relay-based output is needed to control external devices from a centralized control point.
• Building Automation: Can be used to control lighting systems, HVAC, or security equipment in large building automation setups.

This GE DS3800NB1F1B1A module is ideal for users seeking reliable, high-voltage, or high-current relay outputs in industrial automation systems. It enhances the flexibility of GE PLC systems by providing robust control over external devices, with real-time diagnostics and ease of integration into existing infrastructure. A-B 1756-L72
