  • Product Name: GE IC697CPX935 CPU Module

  • Brand: General Electric (GE)

  • Series: Series 90-30 PLC

  • Model Number: IC697CPX935

  • Processor Type:

    • Intel 80C186 microprocessor
    • 16-bit architecture for efficient processing

  • Processing Speed:

    • 1.6 MHz (microprocessor clock speed)

  • Memory:

    • User Memory: 64 KB of battery-backed SRAM for storing user programs and data
    • System Memory: 16 KB of ROM for system firmware and diagnostics
احصل على عرض أسعار
التصنيف:

الوصف

GE+IC697CPX935 PLC Module

Product Name

GE IC697CPX935 PLC Module

Product Description

The GE IC697CPX935 is a CPU module designed for use within the GE Fanuc Series 90-30 Programmable Logic Controller (PLC) systems. This module serves as the central processing unit (CPU) for the Series 90-30 PLC, facilitating the processing of inputs, outputs, and communication with other devices in industrial automation systems.

The IC697CPX935 CPU module offers advanced control and communication capabilities and supports high-speed processing, making it suitable for a wide range of industrial automation tasks. It includes features such as Ethernet communication, enhanced processing speed, and compatibility with various I/O modules and communication networks, ensuring seamless operation in complex automation setups.

This CPU module is widely used in manufacturing, process control, and other automation industries where reliable and scalable control systems are essential.

Product Parameters & Specifications

  • Product Name: GE IC697CPX935 CPU Module

  • Brand: General Electric (GE)

  • Series: Series 90-30 PLC

  • Model Number: IC697CPX935

  • Processor Type:

    • Intel 80C186 microprocessor
    • 16-bit architecture for efficient processing

  • Processing Speed:

    • 1.6 MHz (microprocessor clock speed)

  • Memory:

    • User Memory: 64 KB of battery-backed SRAM for storing user programs and data
    • System Memory: 16 KB of ROM for system firmware and diagnostics

  • Communication Ports:

    • 1x RS-232 (serial port for communication with programming devices)
    • 1x Ethernet port (for high-speed communication with remote devices and network systems)
    • 1x RS-485 (supports Modbus RTU and other protocols for networking and communication)

  • I/O Compatibility:

    • Compatible with GE Series 90-30 I/O modules
    • Supports both digital and analog inputs/outputs through compatible modules

  • Power Supply:

    • Operating Voltage: 5V DC
    • Current Consumption: Approximately 1A at 5V DC

  • Real-Time Clock:

    • Includes a real-time clock for time-based operations and scheduling

  • Environmental Conditions:

    • Operating Temperature Range: 0°C to 60°C (32°F to 140°F)
    • Storage Temperature Range: -40°C to 85°C (-40°F to 185°F)
    • Humidity: 5% to 95% non-condensing

  • Mounting:

    • Rack Mountable
    • Fits into the GE 90-30 PLC rack system

  • Diagnostic Features:

    • LED Indicators: Provides status indicators for system, I/O, and communication health
    • Fault Detection: Built-in diagnostics for troubleshooting and maintenance

  • Communication Protocols Supported:

    • Modbus RTU
    • Ethernet/IP
    • DF1 Protocol
    • GE Fanuc proprietary protocols

  • Programming Languages Supported:

    • Ladder Logic
    • Function Block Diagram (FBD)
    • Structured Text (ST)

  • Dimensions (L x W x H):

    • Approx. 155 mm x 85 mm x 35 mm (L x W x H)

  • Weight:

    • Approx. 0.4 kg (0.88 lbs)

  • Certification:

    • CE, UL, CSA (meets international safety and electromagnetic compatibility standards)

Key Features

  1. High-Speed Processing:
    The IC697CPX935 is equipped with an Intel 80C186 processor running at 1.6 MHz, providing reliable performance for complex automation tasks, making it suitable for real-time control applications.

  2. Ethernet Communication:
    With an Ethernet port, the IC697CPX935 supports high-speed network communication, allowing for efficient remote monitoring, diagnostics, and control, which is vital for distributed automation systems.

  3. Large Memory Capacity:
    This CPU module features 64 KB of user memory for storing control programs and 16 KB of system memory for firmware, offering ample space for complex programs and data handling.

  4. I/O Expansion and Flexibility:
    The IC697CPX935 can be easily integrated with other GE 90-30 I/O modules to expand system I/O capacity. This provides a flexible solution for applications that require significant input/output points.

  5. Built-in Diagnostics:
    LED indicators provide real-time status updates, while built-in diagnostics help to quickly identify and troubleshoot issues in the system.

  6. Multiple Communication Protocols:
    The CPU module supports Modbus RTU, Ethernet/IP, and DF1 Protocol, making it versatile in connecting to various field devices and industrial networks.

  7. Time-Based Control:
    The module’s real-time clock allows for time-based operations, which is essential in applications that require scheduling or time-sensitive control actions.

Applications

The GE IC697CPX935 PLC CPU module is ideal for a variety of industrial automation applications, including:

  • Manufacturing Automation: Used to control assembly lines, robotic arms, conveyors, and other production equipment.

  • Process Control: Ideal for industries such as chemical, pharmaceutical, and food processing, where precise control and monitoring of processes are required.

  • Energy Management: Used in power generation and distribution systems for monitoring and controlling energy flow.

  • Building Automation: For controlling HVAC systems, lighting, and security in large buildings or complexes.

  • Material Handling: In warehouses and distribution centers, controlling material handling systems, conveyors, and sorting equipment.

Conclusion

The GE IC697CPX935 is a reliable, high-performance CPU module designed for use in the GE Series 90-30 PLC systems. With features such as Ethernet communication, large memory capacity, support for multiple communication protocols, and high-speed processing, this module is well-suited for demanding industrial automation applications. Its flexibility, combined with robust diagnostics and scalability, makes it an ideal choice for a wide range of industries. Whether you’re working in manufacturing, energy, or process control, the IC697CPX935 ensures a reliable and efficient control solution for your PLC system.

For additional technical support or more information about integration, please reach out to GE Fanuc or an authorized distributor. 2250ZC35/24 PLC
