GE IS200TREGH1BDB DCS PLC Module

Product Name:

GE IS200TREGH1BDB – Relay Output Module for GE Distributed Control System (DCS) and Programmable Logic Controller (PLC) Systems

Product Description:

The GE IS200TREGH1BDB is a relay output module designed for use within GE’s Mark VIe DCS/PLC systems. It serves as a vital interface for controlling field devices such as motors, valves, alarms, and other critical industrial equipment that require reliable and high-voltage switching capabilities. The module provides multiple relay outputs, allowing for flexible control of various field devices, and is built to perform reliably in demanding industrial environments.

This module is commonly used in industries such as energy generation, oil and gas, water treatment, chemical processing, and manufacturing. It features built-in diagnostic capabilities, enabling real-time monitoring of relay status and fault conditions. With its rugged design and high durability, the IS200TREGH1BDB module ensures the long-term stability and efficiency of automation systems.

Product Parameters & Specifications:

• Model Name: GE IS200TREGH1BDB
• Module Type: Relay Output Module
• Relay Channels: Typically 8 relay output channels
• Relay Type: Electromechanical relays (SPST – Single Pole Single Throw)
• Nominal Control Voltage: 24 VDC (for control signals)
• Switching Voltage:
  • AC Switching Voltage: 250 VAC maximum
  • DC Switching Voltage: 30 VDC maximum
• Maximum Switching Current:
  • AC: 5 A per channel
  • DC: 5 A per channel
• Relay Contact Resistance: <1Ω (at 1A load)
• Power Consumption: 4-6 W (depending on active relays)
• Diagnostic Features:
  • Real-time monitoring for relay health
  • Overcurrent and failure detection
  • Status feedback for each relay channel
• LED Indicators: Provides visual status for relay operation (ON/OFF) and fault conditions
• Cooling Requirements: Passive cooling with adequate system ventilation
• Mounting Type: Rack-mounted within a GE Mark VIe or compatible DCS/PLC control system
• Dimensions: Approx. 13.5 cm (L) x 8.0 cm (W) x 6.5 cm (H)
• Weight: Approx. 1.2 kg
• Material: Industrial-grade housing designed to withstand harsh environmental conditions
• Operating Temperature Range: 0°C to 60°C
• Storage Temperature Range: -20°C to 70°C
• Humidity Range: 5% to 95% non-condensing
• Protection Class: IP20 (suitable for indoor use)
• Certifications: UL, CE, and other relevant industrial certifications
• Field Wiring: Screw terminal blocks for simple and secure field wiring

Additional Features:

• Overload Protection: Prevents relay damage from electrical overloads with built-in safeguards.
• Optical Isolation: Isolates control circuits from relay contacts, protecting against electrical surges and noise.
• Modular Design: Easily integrates into GE’s modular DCS/PLC system architecture, enabling scalable solutions.
• Real-Time Monitoring: Diagnostics provide continuous feedback on relay performance and fault conditions to ensure system reliability.
• Relay Health Monitoring: Features built-in diagnostics that help identify relay faults or wear, ensuring continuous system performance.
• Field Configurable Settings: Allows configuration of delay times and relay behaviors through the control system.

Applications:

• Energy Generation: Controls motors, circuit breakers, protective relays, and other equipment in power plants.
• Oil & Gas: Manages valves, pumps, and other critical control systems in upstream and downstream processes.
• Water Treatment: Controls pumps, valves, and alarm systems in municipal and industrial water treatment plants.
• Manufacturing Automation: Used for controlling robotic arms, conveyors, and other automated systems in manufacturing environments.
• HVAC: Provides relay outputs for managing HVAC systems in commercial and industrial buildings.

Advantages:

• Reliability: Offers robust performance in critical industrial applications where uptime and reliability are paramount.
• Diagnostics: The built-in diagnostics help monitor relay performance and prevent system failures by providing early fault detection.
• Ease of Integration: Compatible with GE’s existing modular DCS/PLC systems, making it easy to integrate into complex automation systems.
• Durability: The module’s design is built to withstand harsh industrial conditions, ensuring long-term operational stability.
• Maintenance Efficiency: LED indicators and diagnostic features streamline maintenance efforts, reducing downtime and improving system availability.

The GE IS200TREGH1BDB relay output module is a reliable, high-performance solution for industrial automation systems, providing precise control of field devices, advanced diagnostics, and seamless integration into GE Mark VIe and similar DCS/PLC systems. 9905-003 PLC
