  • Model: GE IS200TRLYH1BGG
  • Module Type: Relay Output Module
  • Output Channels: 8 output channels (configurable)
  • Relay Type: Electromechanical relays
  • Relay Contact Configuration: Typically Form A (SPST – Single Pole Single Throw), but may vary based on model configuration
  • Nominal Output Voltage: 24 VDC (for control signals)
  • Maximum Switching Voltage: 250 VAC or 30 VDC (depending on load type)
  • Maximum Switching Current: 5 A per channel (typical, can vary based on load)
  • Contact Resistance: Typically less than 1 ohm at 1A current
  • Power Consumption: Typically 3-5 W depending on the number of active outputs
  • LED Status Indicators: Each channel has an LED for indicating relay status (ON/OFF) and fault conditions
  • Diagnostic Features: Built-in diagnostics for fault detection, including relay failure, overcurrent, and open circuit monitoring
  • Mounting Type: Rack-mounted within GE control systems (Mark VIe or similar)
  • Dimensions: Approx. 13.5 cm x 8.0 cm x 5.5 cm (L x W x H)
  • Weight: Approx. 1.0 kg
  • Material: Industrial-grade housing to withstand high temperatures, dust, and industrial chemicals
  • Operating Temperature Range: 0°C to 60°C
  • Storage Temperature Range: -20°C to 70°C
  • Humidity Range: 5% to 95% non-condensing
  • Protection Class: IP20 (suitable for indoor use in dry, non-corrosive environments)
  • Certification: UL, CE, and other relevant industrial certifications
  • Field Wiring: Uses screw terminal blocks or similar connectors for easy field wiring connections
احصل على عرض أسعار
التصنيف:

الوصف

GE IS200TRLYH1BGG DCS PLC Module

The GE IS200TRLYH1BGG is a relay output module designed for use in GE’s Distributed Control Systems (DCS) and Programmable Logic Controllers (PLC). This module plays a critical role in controlling the switching of electrical circuits and devices based on input from the system. It is particularly well-suited for industrial automation applications where precise control and monitoring of relay outputs are required.

Product Name:

GE IS200TRLYH1BGG – Relay Output Module for DCS/PLC Systems

Product Description:

The GE IS200TRLYH1BGG is an advanced relay output module that provides relay contact outputs for GE’s Mark VIe or similar Distributed Control Systems (DCS) and PLCs. This module is designed to interface with external control systems or field devices to provide switching functions. It is commonly used to control electrical devices such as motors, pumps, valves, alarms, and other actuators in industrial automation systems.

With its robust design and high reliability, the IS200TRLYH1BGG is capable of handling high currents and voltages, ensuring safe and reliable operation in industrial environments. The module is equipped with diagnostic features to monitor the health and status of each relay, ensuring that system faults are detected early to minimize downtime.

Key Features:

  • High-Performance Relay Outputs: Capable of controlling devices such as motors, valves, and alarms with reliable relay switching.
  • Multiple Output Channels: Provides multiple relay contacts (typically 8 or more) for controlling a variety of devices.
  • Built-in Diagnostics: Includes diagnostic features for monitoring the operational status of each relay output.
  • Modular and Scalable: Integrates seamlessly with GE’s modular DCS and PLC systems, allowing for easy scaling and customization.
  • High Current and Voltage Handling: Designed to handle high-current and high-voltage load switching.
  • Durability: Built to withstand harsh industrial environments with extended operational lifetimes.

Product Parameters & Specifications:

  • Model: GE IS200TRLYH1BGG
  • Module Type: Relay Output Module
  • Output Channels: 8 output channels (configurable)
  • Relay Type: Electromechanical relays
  • Relay Contact Configuration: Typically Form A (SPST – Single Pole Single Throw), but may vary based on model configuration
  • Nominal Output Voltage: 24 VDC (for control signals)
  • Maximum Switching Voltage: 250 VAC or 30 VDC (depending on load type)
  • Maximum Switching Current: 5 A per channel (typical, can vary based on load)
  • Contact Resistance: Typically less than 1 ohm at 1A current
  • Power Consumption: Typically 3-5 W depending on the number of active outputs
  • LED Status Indicators: Each channel has an LED for indicating relay status (ON/OFF) and fault conditions
  • Diagnostic Features: Built-in diagnostics for fault detection, including relay failure, overcurrent, and open circuit monitoring
  • Mounting Type: Rack-mounted within GE control systems (Mark VIe or similar)
  • Dimensions: Approx. 13.5 cm x 8.0 cm x 5.5 cm (L x W x H)
  • Weight: Approx. 1.0 kg
  • Material: Industrial-grade housing to withstand high temperatures, dust, and industrial chemicals
  • Operating Temperature Range: 0°C to 60°C
  • Storage Temperature Range: -20°C to 70°C
  • Humidity Range: 5% to 95% non-condensing
  • Protection Class: IP20 (suitable for indoor use in dry, non-corrosive environments)
  • Certification: UL, CE, and other relevant industrial certifications
  • Field Wiring: Uses screw terminal blocks or similar connectors for easy field wiring connections

Additional Features:

  • Optical Isolation: Provides optical isolation between the control signals and relay outputs to protect the system from voltage spikes and electrical noise.
  • Status Monitoring: Each relay output channel has an associated LED indicator for real-time operational feedback.
  • Overload Protection: The module includes overload protection for relay contacts, protecting both the module and external devices.
  • Configurable Relays: Some versions may allow for configuration of relay timing, such as on-delay or off-delay, through the DCS/PLC system.
  • Flexible Integration: Compatible with GE’s DCS and PLC control systems, such as Mark VIe, to provide flexible and scalable control solutions.

Applications:

The GE IS200TRLYH1BGG relay output module is suitable for a wide variety of industrial applications that require reliable switching of electrical circuits. Key applications include:

  • Industrial Automation: Used to control actuators, motors, valves, and other equipment in automated manufacturing lines.
  • Power Generation: Controls power distribution circuits, emergency stop circuits, and other critical relay-based systems in power plants.
  • Oil & Gas: Switches and controls equipment such as pumps, valves, and alarms in oil refineries, pipeline systems, and offshore platforms.
  • Water Treatment: Switches water treatment equipment, pumps, and control valves in municipal and industrial water treatment facilities.
  • Process Control: Controls key process equipment, including heating, ventilation, and air conditioning (HVAC) systems, and other process machinery.

Advantages:

  • Reliable Switching: High-quality relays ensure long service life and reliable switching of field devices.
  • Simple Integration: Easily integrates with existing GE control systems, minimizing installation complexity.
  • Diagnostic Capabilities: Built-in diagnostic features allow quick fault detection, reducing maintenance time and improving system uptime.
  • Durability: Designed to perform reliably in challenging industrial environments, with protection against electrical noise and external disturbances.
  • Scalable and Modular: Can be expanded or customized as part of a larger system, allowing for flexible automation solutions.

Selection and Installation Considerations:

  • Selection Consideration: The GE IS200TRLYH1BGG is ideal for applications where reliable relay switching is required to control electrical devices. It should be selected based on the voltage and current ratings of the devices being controlled.

  • Installation Precautions:

    • Verify that the relay output channels are compatible with the equipment being controlled (e.g., motor ratings, alarm voltages).
    • Ensure that wiring is properly routed to prevent accidental short circuits or signal interference.
    • Perform regular maintenance checks to ensure the integrity of the relay contacts and to monitor for wear or corrosion.
    • Use appropriate protection (e.g., fuses) to prevent damage from electrical surges or overloads.
    • Ensure proper cooling and ventilation in the installation area to maintain optimal operating conditions.

For more detailed specifications, pricing, or support for the GE IS200TRLYH1BGG relay output module, you can contact GE Automation or a local distributor.

This relay output module is a key component in many industrial automation systems, offering excellent reliability and ease of integration for a wide range of applications. 140XTS00203 CPU
140XTS10206 PLC
