  • Model Number: ICS Triplex T8191
  • Module Type: Digital Input/Output (I/O) Module for safety-critical systems.
  • Architecture: Part of the TMR (Triple Modular Redundancy) system in ICS Triplex architecture.
  • Application: Used in DCS (Distributed Control Systems) and PLC (Programmable Logic Controllers) for real-time control in safety and process automation applications.

Electrical Specifications:

  • Input Voltage: Typically operates on 24V DC for logic and control systems (standard for ICS Triplex modules).
  • Power Consumption: Around 8W to 15W depending on configuration and number of connected inputs/outputs.

I/O Specifications:

  • Digital Inputs:
    • Typically, 16-32 digital input channels (depends on configuration).
    • Accepts dry contact, voltage, and current signals.
    • Input ranges: 0-24V DC or dry contact closure (depending on model configuration).
  • Digital Outputs:
    • Typically 16-32 digital output channels.
    • Output types include relay outputs, open collector, or solid-state outputs, with voltage ratings of 24V DC (common configuration).
احصل على عرض أسعار
التصنيف:

الوصف

The ICS Triplex T8191 is a Distributed Control System (DCS) PLC Module developed by ICS Triplex, which is a part of Emerson Automation Solutions. This module is designed to work in industrial control systems for high-integrity applications such as process automation, safety-critical control systems, and mission-critical environments. The T8191 module provides high-performance input and output functionality while ensuring safety and reliability, meeting stringent industry standards.

Here’s a breakdown of the ICS Triplex T8191 DCS PLC Module:

Product Name

  • ICS Triplex T8191 DCS PLC Module

Product Description

The ICS Triplex T8191 is a high-integrity input/output (I/O) module used within the Triplex Safety Systems. It is designed for real-time signal processing and is typically used for safety-critical applications in industries like oil & gas, chemical processing, power generation, and other sectors where safety and reliability are paramount.

This module integrates seamlessly into the ICS Triplex TMR (Triple Modular Redundancy) architecture, providing redundancy and fault tolerance to enhance system availability and prevent single points of failure. It ensures that control actions are performed reliably, even in the event of faults in the control loop or communication system.

Product Parameters & Specifications

General Features:

  • Model Number: ICS Triplex T8191
  • Module Type: Digital Input/Output (I/O) Module for safety-critical systems.
  • Architecture: Part of the TMR (Triple Modular Redundancy) system in ICS Triplex architecture.
  • Application: Used in DCS (Distributed Control Systems) and PLC (Programmable Logic Controllers) for real-time control in safety and process automation applications.

Electrical Specifications:

  • Input Voltage: Typically operates on 24V DC for logic and control systems (standard for ICS Triplex modules).
  • Power Consumption: Around 8W to 15W depending on configuration and number of connected inputs/outputs.

I/O Specifications:

  • Digital Inputs:
    • Typically, 16-32 digital input channels (depends on configuration).
    • Accepts dry contact, voltage, and current signals.
    • Input ranges: 0-24V DC or dry contact closure (depending on model configuration).
  • Digital Outputs:
    • Typically 16-32 digital output channels.
    • Output types include relay outputs, open collector, or solid-state outputs, with voltage ratings of 24V DC (common configuration).

Signal Types:

  • Digital Inputs: Typically for binary signals, such as switches, relays, or other binary field devices.
  • Digital Outputs: Used for controlling devices like solenoids, relays, or other binary control elements in industrial systems.

Redundancy Features:

  • TMR (Triple Modular Redundancy): Provides built-in fault tolerance by using three independent modules to ensure continuous operation and reliability in case of faults or failures in one or two of the modules. The system compares inputs from the three modules to determine the correct output, thus maintaining system integrity.

Communication & Compatibility:

  • Protocol: Compatible with ICS Triplex TMR architecture and can communicate using redundant communication networks like Modbus TCP, Modbus RTU, and Ethernet.
  • Integration with Triplex Safety Systems: The module is designed to integrate easily with the Triplex TMR Control System, enabling it to serve as part of a highly reliable, redundant control loop.

Diagnostic and Monitoring Features:

  • Built-in Diagnostics: Includes continuous health monitoring of inputs, outputs, and communication paths. Diagnostics include fault detection for signal integrity, module health, wiring faults, and communication errors.
  • LED Indicators: Provides visual indicators for power, communication status, I/O activity, and faults to allow for easy troubleshooting.

Environmental and Mechanical Specifications:

  • Operating Temperature: Typically operates in the range of -20°C to 60°C. Extended ranges may be available in special configurations.
  • Humidity: Typically 5% to 95% non-condensing.
  • Vibration: Designed to meet industrial standards for vibration resistance, ensuring reliable operation even in harsh environments.
  • Dimensions: Typically around 130mm x 160mm x 60mm (may vary depending on configuration).
  • Weight: Around 0.8 to 1.2 kg, depending on the configuration.

Safety & Compliance:

  • IEC61508: Functional Safety certification, making it suitable for use in safety-critical applications.
  • ISO9001: Quality management standards.
  • UL Listed: Meets UL safety standards for industrial use.
  • CE Marked: Conforms to European Union safety, health, and environmental requirements.

Key Features & Benefits

  1. Triple Modular Redundancy (TMR): The T8191 benefits from TMR architecture, providing superior reliability by ensuring that the system can tolerate the failure of one or even two modules while continuing to function safely and effectively. This is ideal for mission-critical systems in industries like power, oil & gas, and chemical processing.

  2. High-Integrity I/O: The module provides high-integrity digital I/O with advanced diagnostics and fault detection features, essential for safety applications that require continuous, fault-tolerant operation.

  3. Ease of Integration: The module integrates seamlessly into the ICS Triplex TMR systems, allowing for easy expansion and compatibility with other ICS Triplex products. It also supports various communication protocols for connectivity and integration.

  4. Robust Diagnostics and Monitoring: Built-in diagnostics allow operators to monitor the health and performance of the system continuously. The LED indicators and remote monitoring capabilities provide clear, real-time visibility into the status of each I/O channel.

  5. Flexible I/O Types: Supports a variety of digital I/O signal types, making it suitable for a wide range of industrial applications, from basic on/off control to more complex process automation tasks.

  6. Compliant with Industry Standards: The T8191 module meets industry standards for functional safety and reliability, ensuring it can be used in safety-critical environments where system failure can result in catastrophic outcomes.

Applications and Use Cases

  • Oil & Gas: In offshore platforms, refineries, and pipelines, this module is used for critical process control tasks like emergency shutdown systems (ESD), burner management, and emergency response.
  • Power Generation: In power plants, it is used for controlling turbine generators, reactor cooling systems, and boiler control. The TMR architecture ensures that any faults in one module won’t affect the overall operation of critical control systems.
  • Chemical Processing: In chemical plants, this module can control process variables such as temperature, pressure, flow, and chemical composition, ensuring safe and reliable operation.
  • Water Treatment: Used to monitor and control water treatment systems for both municipal and industrial applications, ensuring optimal performance in filtration, chemical dosing, and flow regulation.
  • Manufacturing & Automation: In manufacturing environments, it ensures reliable operation of machinery and automation systems, preventing downtime or system failure during production cycles.

Comparison with Competitors

  • Emerson: As part of the Emerson family, the ICS Triplex T8191 is known for its high reliability and advanced diagnostics, which sets it apart from traditional PLC modules used in non-safety-critical applications. Competitors like Siemens or Schneider Electric also offer DCS and PLC modules, but ICS Triplex’s focus on Triple Modular Redundancy (TMR) gives it a competitive edge in highly critical industries where safety is paramount.

  • Siemens S7-1500: Siemens provides highly flexible and powerful automation systems, but their offerings may not match the high-integrity, fault-tolerant capabilities of the ICS Triplex T8191 module, especially for safety-critical systems.

Selection Tips and Considerations

  1. Safety-Critical Requirements: If your application is safety-critical, such as emergency shutdown or fail-safe processes, the T8191 module’s Triple Modular Redundancy architecture makes it an excellent choice for ensuring continued safe operation under fault conditions.

  2. System Compatibility: Ensure that the ICS Triplex T8191 is compatible with your existing Triplex Safety System or other systems in use. If you already use ICS Triplex TMR for your control needs, this module will integrate seamlessly.

  3. Field Device Compatibility: Consider the types of devices (digital I/O signals, relays, or solenoids) you need to interface with. The T8191 module can handle a wide range of I/O types, but confirming compatibility with your specific field devices is essential.

For more detailed technical specifications, installation manuals, or to purchase the module, please contact Emerson Automation Solutions or an authorized distributor.
