Product Name

ICS TRIPLEX T8193 Trusted TMR Universal Input Module

Product Description

The ICS TRIPLEX T8193 Trusted TMR Universal Input Module is a key component of the ICS TRIPLEX Trusted System, designed for high-integrity applications requiring triple modular redundancy (TMR). This module offers versatile input capabilities, supporting a wide range of analog and digital signals, ensuring flexibility in various industrial settings. Specifically, the ICS TRIPLEX T8193 allows for precise monitoring and control of critical processes, enhancing safety and reliability. The ICS TRIPLEX T8193 universal input module excels in providing robust and fault-tolerant data acquisition. Furthermore, the ICS TRIPLEX T8193 is engineered to minimize downtime and ensure continuous operation, a hallmark of ICS TRIPLEX systems. The ICS TRIPLEX T8193 module seamlessly integrates into existing Trusted systems, providing enhanced input capabilities without compromising system integrity.

Product Parameters

• ICS TRIPLEX+T8193
• Input Types: Analog Voltage, Analog Current, Digital Inputs (configurable)
• Resolution: 16-bit
• Input Range: Configurable based on input type (e.g., 0-10V, 4-20mA)
• Accuracy: Typically ±0.1% of full scale
• Isolation: Galvanic isolation between channels and system backplane
• Operating Temperature: -40°C to +70°C
• Power Supply: 24V DC
• Redundancy: Triple Modular Redundancy (TMR)
• Diagnostic Features: Comprehensive online diagnostics for fault detection and reporting
• Compliance: SIL3 certified (IEC 61508)

Advantages and Features

• Triple Modular Redundancy (TMR): Provides exceptional fault tolerance and availability. Three independent channels process the same input signal, and a voting system determines the correct output, ensuring continuous operation even if one channel fails.
• Universal Input Capability: Supports a wide range of analog and digital input signals, reducing the need for multiple specialized modules.
• High Accuracy and Resolution: Ensures precise monitoring and control of critical processes.
• Galvanic Isolation: Protects the system from ground loops and electrical noise, improving signal integrity.
• Comprehensive Diagnostics: Enables early detection of potential problems, facilitating proactive maintenance and reducing downtime.
• SIL3 Certification: Complies with stringent safety standards, making it suitable for safety-critical applications.

Application Areas & Application Cases

• Oil and Gas: Emergency shutdown systems (ESD), fire and gas detection systems, process control.
  • Example: Monitoring pressure and temperature in a natural gas pipeline to prevent over-pressure situations.
• Chemical Processing: Reactor control, safety interlock systems, critical process monitoring.
  • Example: Controlling chemical feed rates in a batch reactor to ensure safe and efficient production.
• Power Generation: Turbine control, boiler control, generator protection.
  • Example: Monitoring turbine speed and vibration to prevent catastrophic failures.
• Nuclear Power: Reactor protection systems, emergency core cooling systems.
  • Example: Monitoring reactor coolant temperature and pressure to initiate emergency shutdown procedures if necessary.
• Pharmaceuticals: Batch process control, environmental monitoring, quality control systems.
  • Example: Monitoring temperature and humidity in a cleanroom to maintain product quality.

Competitive Product Comparison

Note: This table is a general comparison. Specific product models from competitors would need to be compared for a more accurate assessment.

Selection Advice

• Safety Requirements: If the application requires SIL3 certification and high availability, the ICS TRIPLEX T8193 is an excellent choice due to its TMR architecture and safety compliance.
• Input Signal Types: Consider the variety of input signals that need to be monitored. The ICS TRIPLEX T8193‘s universal input capability reduces the need for multiple specialized modules.
• Environmental Conditions: Ensure the module’s operating temperature range (-40°C to +70°C) is suitable for the application environment.
• Budget: TMR systems typically have a higher initial cost than non-redundant systems. However, the increased availability and safety can justify the investment in critical applications.

Precautions

• Proper Installation: Follow the manufacturer’s instructions carefully to ensure proper installation and wiring.
• Regular Maintenance: Perform regular maintenance and calibration to ensure accuracy and reliability.
• Environmental Protection: Protect the module from excessive moisture, dust, and vibration.
• Power Supply Quality: Ensure a stable and reliable 24V DC power supply to prevent malfunctions.
• Software Compatibility: Verify compatibility with the existing ICS TRIPLEX Trusted System software.

We are your trusted partner, offering sales and technical support for the ICS TRIPLEX T8193 and other automation components. Contact us for special discounts and pricing. We are at your service!
