KEBA KeTop T20e-r00-Am0-CE6

الوصف

KEBA KeTop T20e-r00-Am0-CE6 DCS PLC Module

Product Name:

KEBA KeTop T20e-r00-Am0-CE6 DCS PLC Module

Product Description:

The KEBA KeTop T20e-r00-Am0-CE6 is a high-performance and flexible HMI (Human-Machine Interface) terminal designed for industrial automation, especially when integrated with Distributed Control Systems (DCS) or Programmable Logic Controllers (PLC). This model from KEBA is part of the KeTop T20 series and offers advanced features for controlling and monitoring processes in real-time.

It is particularly useful in applications that demand high mobility and ergonomic control. The KeTop T20e-r00-Am0-CE6 combines robust hardware with versatile software tools to enhance operator efficiency in industrial settings, offering smooth touch-based interaction for operators who need quick access to critical process parameters and data.

This HMI is typically employed in manufacturing plants, process control systems, and other industrial environments where operators need a mobile interface to manage complex automated systems. The KeTop T20 series is known for its rugged design, ease of use, and high-performance display capabilities, making it an essential tool for modern industrial automation.

Product Parameters & Specifications:

• Model: KEBA KeTop T20e-r00-Am0-CE6

• Display:

  • Type: 10.1″ LED touchscreen (TFT)
  • Resolution: 1280 x 800 pixels (WXGA)
  • Touch: Capacitive multi-touch technology
  • Brightness: 800 cd/m² (ideal for indoor/outdoor applications)
  • Viewing Angle: 170° horizontal and vertical
  • Contrast Ratio: 1000:1
  • Display Colors: 16.7 million colors

• Processor:

  • Type: ARM-based processor (quad-core or higher)
  • CPU Speed: 1.5 GHz or higher
  • RAM: 2 GB or higher
  • Storage: 16 GB flash storage (expandable via SD card or USB)

• Operating System:

  • OS: Windows Embedded Compact 7 (CE6)
  • Software: Compatible with KEBA’s software tools for HMI design and development (e.g., KeControl)

• Connectivity:

  • Ethernet: 2 x 10/100/1000 Mbps Ethernet (supports industrial protocols such as Modbus TCP, EtherCAT, OPC UA, etc.)
  • USB Ports: 2 x USB 2.0 (for peripheral devices)
  • Wi-Fi: Optional (via USB Wi-Fi dongle)
  • Bluetooth: Optional
  • Serial Ports: RS232 and RS485 for communication with PLC or DCS systems
  • SD Card Slot: Yes, for additional storage or data logging

• Power Supply:

  • Voltage Range: 24 V DC
  • Power Consumption: Approx. 10 W (depending on usage)

• Environmental Specifications:

  • Operating Temperature: -10°C to +60°C
  • Storage Temperature: -20°C to +70°C
  • Humidity: 10% to 90% non-condensing
  • Protection Rating: IP65 (front panel, dust-tight and water-resistant)
  • Shock Resistance: 50 g (withstands industrial shock and vibration)
  • Vibration Resistance: 5 Hz to 500 Hz, 1 g

• Physical Specifications:

  • Dimensions: 273 mm x 197 mm x 45 mm
  • Weight: Approx. 1.1 kg
  • Mounting: Wall or panel-mountable
  • Ergonomics: Light and portable with an integrated handle for mobile operation

• User Interface:

  • Touchscreen: Multi-point capacitive touchscreen for intuitive interaction
  • Buttons: 2 physical keys for power and emergency reset (customizable)
  • Operating System Support: Windows-based, making it compatible with a wide range of industrial software packages.

• Additional Features:

  • Audio Output: Built-in speaker for alarms and notifications
  • Expansion: Supports external peripherals like barcode scanners, cameras, and printers via USB or serial connections.
  • Customizable Interfaces: User-configurable interfaces using KEBA’s KeControl or third-party HMI software.
  • Remote Management: Supports remote configuration, monitoring, and diagnostics over the network.

Key Features & Advantages:

1. High-Performance Display: With its high-resolution 10.1” touchscreen and excellent visibility under varied lighting conditions, the KeTop T20e provides a clear, responsive interface for operators, ensuring easy data input and monitoring.

2. Robust and Rugged Design: Built with industrial-grade materials, this device offers excellent resistance to environmental factors like dust, moisture, and mechanical vibrations. Its IP65 rating guarantees protection in harsh industrial settings.

3. Mobile and Ergonomic: The integrated handle makes it easy to move the device around, offering mobility and flexibility in production environments. It’s perfect for mobile HMI solutions or operators who need to interact with multiple machines.

4. Flexible Connectivity: The KeTop T20e supports multiple communication protocols and interfaces, including Ethernet, Wi-Fi, Bluetooth, USB, and serial ports for seamless integration with PLC, DCS, and other industrial devices.

5. Wide Temperature Range: Designed to operate in harsh environments with a temperature range of -10°C to +60°C, making it ideal for industries such as automotive, food processing, and chemical manufacturing.

6. Power Efficiency: With a relatively low power consumption of 10 W, the KeTop T20e is energy-efficient, contributing to overall system efficiency in large-scale installations.

7. Software Compatibility: Compatible with KEBA’s KeControl software suite, allowing for quick and easy creation of intuitive and user-friendly graphical interfaces for monitoring and control.

Applications and Use Cases:

• Industrial Automation: The KeTop T20e is often used in automated factories and assembly lines, where operators need to monitor and control production processes remotely and efficiently.

• Process Control: Suitable for applications in process control systems, such as monitoring chemical plants, oil & gas pipelines, and water treatment facilities, providing real-time data feedback.

• Energy Management: Integrated into energy management systems for tracking and optimizing energy consumption in industries.

• Robotics: Provides a mobile HMI solution for robotic applications, where operators need to interact with and control robotic arms or automated machinery.

• Automated Warehousing: Used in automated warehouses or logistics centers, where workers need a mobile device to interface with conveyor systems and robotic handlers.

Comparison with Competing Products:

Compared to other industrial HMIs, the KeTop T20e stands out due to its compact, mobile design, making it easy for operators to move it between different machines and stations. It’s highly customizable and integrates with a wide range of industrial protocols, ensuring flexibility in various automation applications.

Unlike some competing products, the KeTop T20e‘s use of Windows Embedded Compact 7 (CE6) ensures compatibility with a variety of software packages, reducing development time and increasing operational efficiency.

Selection Tips and Considerations:

• Selection Tip: Ideal for mobile or remote control applications where high mobility, robust construction, and flexible communication options are needed. It’s especially useful when integrated with DCS and PLC systems for large-scale automation projects.

• Considerations: Ensure the module is compatible with your existing industrial system, particularly regarding communication protocols and software tools.

This detailed overview provides insights into the KEBA KeTop T20e-r00-Am0-CE6 HMI terminal, covering its specifications, features, and typical use cases. If you need further assistance in choosing or configuring the right HMI for your industrial automation system, feel free to ask!
