Product Name:

MOTOROLA MVME162-012 DCS/PLC Module

Product Description:

The MOTOROLA MVME162-012 is a VMEbus-based DCS/PLC module designed for high-performance applications in industrial control systems, especially in automation, real-time processing, and distributed control environments. This module offers advanced embedded computing capabilities with high processing power and reliability for controlling critical systems.

The MVME162-012 is part of Motorola’s MVME series, which is widely recognized for its ruggedness and capability to operate in demanding industrial environments. It’s designed to work within a VMEbus architecture, which is a modular, scalable, and high-throughput system typically used in embedded control applications, including industrial automation, communication systems, and military applications.

The MVME162-012 provides a combination of VME processing capabilities, I/O control, and communication features, making it suitable for Distributed Control Systems (DCS) and Programmable Logic Controllers (PLC) applications. This module is engineered to offer exceptional performance in industrial, automotive, and defense systems where low-latency and real-time processing are crucial.

Product Parameters:

• Module Type: DCS/PLC Module, VMEbus-based Embedded Processor.
• Processor Type: Motorola 68k Series Processor (typically 68000 family).
• Architecture: VMEbus (Versa Module Europa).
• Model Number: MVME162-012.
• Application: Suitable for control, automation, and embedded systems, especially in industrial and military environments.
• Form Factor: VME-Standard 6U form factor, making it easy to integrate into existing VME-based systems.

Product Specifications:

1. Processor and Computing Power:

• Processor Type:

  • Motorola 68040 microprocessor (or similar in the MVME162 series).
  • Processor Speed: Typically operates at speeds of 25 MHz or 33 MHz, providing substantial computational power for control systems.
  • Processing Power: Offers real-time processing capabilities to handle high-speed control loops, automation processes, and data acquisition systems.

• Co-Processor Options:

  • Option for Floating Point Unit (FPU) or additional co-processing capabilities, depending on the application requirements.

2. Memory:

• RAM:
  • Standard Configuration: Typically comes with 8 MB of DRAM (expandable to 16 MB or 32 MB, depending on the configuration).
• Non-Volatile Storage:
  • Includes flash memory or EEPROM for storing critical system data and parameters.
• Cache Memory:
  • Typically includes L2 cache to improve the speed of data access, especially during heavy processing tasks.

3. I/O and Expansion:

• VMEbus Interface:

  • The module adheres to VMEbus standards for high-speed data transfer, ensuring compatibility with other VME systems.
  • Supports multiple VME I/O cards for expansion, making it adaptable to various control needs.

• Serial Ports:

  • 2 x RS-232 serial ports for communication with external systems or devices.
  • Support for additional serial communication via expansion options (RS-422, RS-485, etc.).

• Parallel Ports:

  • Optional parallel port interfaces (depending on configuration) for connecting to external PLCs or I/O devices.

• I/O Expansion Slots:

  • Typically features 2-3 slots for additional I/O cards, depending on the system configuration.

4. Communication and Networking:

• Ethernet Interface:

  • Typically supports 10/100 Base-T Ethernet connectivity for real-time data transfer, remote access, and integration into larger control systems or networks.

• SCSI Interface:

  • May support SCSI for connecting additional peripherals like hard drives or external storage devices.

• Fieldbus Support:

  • Can support various industrial protocols (e.g., Modbus, Profibus, CAN bus, etc.), making it adaptable to DCS and PLC applications.

5. Power Requirements:

• Input Voltage:

  • Typically operates with +5V DC or +12V DC for power input, depending on the system configuration.
  • Power Consumption: Around 15-25W, depending on the specific configuration and load.

• Power Protection:

  • Includes built-in protection mechanisms to prevent power surges or fluctuations from damaging the module.

6. Environmental and Compliance Specifications:

• Operating Temperature Range:

  • Typically designed to operate in the range of 0°C to +70°C (32°F to 158°F).

• Storage Temperature Range:

  • Can tolerate temperatures ranging from -40°C to +85°C (-40°F to 185°F).

• Humidity Range:

  • Designed for environments with 5% to 95% relative humidity (non-condensing).

• Compliance:

  • CE Marking for compliance with European Union safety standards.
  • UL Approval for safety compliance in North America.

7. Mechanical and Physical Specifications:

• Form Factor:
  • 6U VMEbus format, allowing easy integration into existing VME systems or racks.
• Dimensions:
  • Approximately 160 mm x 233 mm x 25 mm (HxWxD).
• Weight:
  • Typically weighs around 0.5–1 kg depending on configuration.

Key Features and Benefits:

• VMEbus Architecture: Supports high-speed data transfer and is compatible with a wide range of industrial systems.
• High-performance Processor: The Motorola 68040 processor ensures that the module can handle complex computations required for real-time control and automation tasks.
• I/O Expansion Flexibility: Offers a range of I/O expansion options for interfacing with external devices and peripherals.
• Reliable and Rugged: Designed for operation in industrial environments, with protection against power surges and adverse environmental conditions.
• Real-time Capabilities: Perfect for real-time control systems where timing and performance are critical.
• Ethernet and Serial Communications: Multiple communication options allow integration with larger control systems or direct connection to field devices.

Applications:

• Industrial Automation: The MVME162-012 is used in industrial control systems for automating machinery, equipment, and processes.
• Distributed Control Systems (DCS): Provides computing power to support complex control and monitoring in large industrial plants.
• Programmable Logic Controllers (PLC): Can be integrated as part of a PLC setup for controlling manufacturing processes and other automation tasks.
• Defense and Aerospace: Used in embedded systems for mission-critical applications, such as aircraft control systems and defense electronics.
• Telecommunication Systems: Used for managing communication networks and systems that require real-time processing and control.

Conclusion:

The MOTOROLA MVME162-012 is a versatile and robust embedded processor module suitable for demanding industrial environments. Its VMEbus compatibility, combined with its real-time processing capabilities, Ethernet communication, and expandable I/O options, make it an excellent choice for DCS and PLC applications. The module’s reliability and scalability make it ideal for automation, control systems, and real-time processing in industrial, military, and telecommunications sectors.
