Name: PEPPERL & FUCHS RSD-BO-EX4 - RUNSHENG
Price: 8888.00 CNY
Availability: InStock

PEPPERL & FUCHS RSD-BO-EX4

The model number for this module breaks down to reveal its key functions and safety features:

RSD (Remote System Digital): This indicates the module is part of Pepperl+Fuchs’s modular remote I/O family. These systems are ideal for connecting a large number of sensors and actuators in hazardous areas (like Zone 1 or Zone 2) to a central control system (PLC or DCS) in a safe area, which simplifies wiring and reduces installation costs.
BO (Binary Output): This signifies its core function as a binary output module. A “binary” or “digital” output has only two states: ON or OFF. This module is specifically designed to provide a switched voltage source to activate or deactivate devices like solenoid valves, lamps, or alarms. Each of the four outputs acts as a 24V voltage source with a limited current to ensure safety.
EX4 (Explosion Protection): The “Ex” designation confirms that the module is certified for use in hazardous areas. It achieves this through intrinsic safety (Ex ia), a protection technique that limits the electrical and thermal energy of the circuit to a level too low to ignite a flammable mixture of gas, vapor, or dust. The outputs are also capable of monitoring for short circuits and wire breaks on the field circuits, which enhances both safety and diagnostic capabilities.

In essence, the RSD-BO-EX4 acts as a critical interface, taking low-power control signals from a PLC and converting them into safe, reliable, and controlled power to operate essential equipment in a dangerous environment, all while providing advanced diagnostics.

الوصف

The Pepperl+Fuchs RSD-BO-EX4 is an intrinsically safe binary output module designed for remote I/O systems operating in hazardous areas. Its primary function is to safely control and provide power to up to four external field devices, such as solenoid valves or alarms, located in a potentially explosive atmosphere.

Technical Breakdown 🛠️

The model number for this module breaks down to reveal its key functions and safety features:

RSD (Remote System Digital): This indicates the module is part of Pepperl+Fuchs’s modular remote I/O family. These systems are ideal for connecting a large number of sensors and actuators in hazardous areas (like Zone 1 or Zone 2) to a central control system (PLC or DCS) in a safe area, which simplifies wiring and reduces installation costs.
BO (Binary Output): This signifies its core function as a binary output module. A “binary” or “digital” output has only two states: ON or OFF. This module is specifically designed to provide a switched voltage source to activate or deactivate devices like solenoid valves, lamps, or alarms. Each of the four outputs acts as a 24V voltage source with a limited current to ensure safety.
EX4 (Explosion Protection): The “Ex” designation confirms that the module is certified for use in hazardous areas. It achieves this through intrinsic safety (Ex ia), a protection technique that limits the electrical and thermal energy of the circuit to a level too low to ignite a flammable mixture of gas, vapor, or dust. The outputs are also capable of monitoring for short circuits and wire breaks on the field circuits, which enhances both safety and diagnostic capabilities.

Typical Applications 🏭

Oil & Gas: Controlling solenoid valves on pipelines, actuators in refineries, and warning alarms on offshore platforms.
Chemical Industry: Activating control valves and other discrete devices in plants where flammable chemicals are present.
Wastewater Treatment: Operating valves and pumps in areas where methane gas may accumulate.
Pharmaceuticals: Controlling process equipment in sterile environments with explosive solvents.
