Triconex 3515 Pulse totalizer, 24 VDC, 32 pts.

Key Features and Benefits



  • Triple Modular Redundancy (TMR): The 3515 module uses the TMR architecture, which is a hallmark of Triconex systems. It features three independent input channels that process the pulse count data in parallel. The main processors then use a two-out-of-three (2oo3) voting mechanism to ensure the data is accurate and free from errors caused by a single point of failure. This design guarantees uninterrupted operation and the highest level of system integrity.
  • High-Accuracy Counting: The module provides precise counting with an impressive resolution of up to 0.1 microseconds, ensuring highly accurate measurement. It can handle pulse frequencies from 1 Hz to 20 kHz, making it versatile for a wide range of industrial applications.
  • 32 Independent Channels: The module offers 32 independent, 31-bit counters. This high density of input points allows you to connect multiple pulse-generating devices to a single module, simplifying wiring and reducing the need for additional hardware.
  • Opto-Isolated Inputs: The inputs are optically isolated to minimize electrical interference and noise, ensuring that the pulse counts are accurate and reliable. This isolation also enhances the integrity and safety of the system.
  • Comprehensive Diagnostics: The 3515 includes built-in diagnostics for each channel. This allows for easy troubleshooting and maintenance by quickly identifying any faults or anomalies in the pulse input signals or the module itself.
  • Hot-Swap Capability: Like other Triconex I/O modules, the 3515 can be replaced online without disrupting the process. This hot-swap capability is crucial for maintaining plant availability and minimizing downtime during maintenance.



Technical Specifications



Feature Specification
Product Type Pulse Totalizer Input (PTI) Module
Model Number 3515
Input Points 32 (31-bit counters)
Input Voltage 24 VDC (5 V to 24 VDC range)
Frequency Range 1 Hz to 20 kHz
Architecture Triple Modular Redundancy (TMR)
Resolution 0.1 microseconds
Isolation Opto-isolated, non-commoned inputs
Diagnostics Continuous, per-channel diagnostics
التصنيف:

الوصف

Triconex 3515 Pulse Totalizer Module



The Triconex 3515 is a specialized Pulse Totalizer Input (PTI) module designed for use in Triconex safety instrumented systems (SIS). It’s an integral component for applications that require high-integrity pulse counting, such as precise flow measurement or monitoring total revolutions of equipment. The module’s core function is to count a large number of pulses from field devices and provide an accurate, fault-tolerant total to the main processors.




Key Features and Benefits



  • Triple Modular Redundancy (TMR): The 3515 module uses the TMR architecture, which is a hallmark of Triconex systems. It features three independent input channels that process the pulse count data in parallel. The main processors then use a two-out-of-three (2oo3) voting mechanism to ensure the data is accurate and free from errors caused by a single point of failure. This design guarantees uninterrupted operation and the highest level of system integrity.
  • High-Accuracy Counting: The module provides precise counting with an impressive resolution of up to 0.1 microseconds, ensuring highly accurate measurement. It can handle pulse frequencies from 1 Hz to 20 kHz, making it versatile for a wide range of industrial applications.
  • 32 Independent Channels: The module offers 32 independent, 31-bit counters. This high density of input points allows you to connect multiple pulse-generating devices to a single module, simplifying wiring and reducing the need for additional hardware.
  • Opto-Isolated Inputs: The inputs are optically isolated to minimize electrical interference and noise, ensuring that the pulse counts are accurate and reliable. This isolation also enhances the integrity and safety of the system.
  • Comprehensive Diagnostics: The 3515 includes built-in diagnostics for each channel. This allows for easy troubleshooting and maintenance by quickly identifying any faults or anomalies in the pulse input signals or the module itself.
  • Hot-Swap Capability: Like other Triconex I/O modules, the 3515 can be replaced online without disrupting the process. This hot-swap capability is crucial for maintaining plant availability and minimizing downtime during maintenance.



Technical Specifications



Feature Specification
Product Type Pulse Totalizer Input (PTI) Module
Model Number 3515
Input Points 32 (31-bit counters)
Input Voltage 24 VDC (5 V to 24 VDC range)
Frequency Range 1 Hz to 20 kHz
Architecture Triple Modular Redundancy (TMR)
Resolution 0.1 microseconds
Isolation Opto-isolated, non-commoned inputs
Diagnostics Continuous, per-channel diagnostics




Common Applications



The Triconex 3515 is ideal for safety and critical control applications that depend on accurate pulse counting. These applications include:

  • Flow Measurement: Using pulse-generating flow meters to measure and totalize the volume of liquids or gases in a pipeline.
  • Turbine Control: Counting the total revolutions of a turbine or other rotating equipment for performance monitoring or safety interlocks.
  • Batching and Blending: Precisely measuring the quantity of materials being added to a batch process.
  • Emergency Shutdown Systems (ESD): Receiving pulse counts from critical sensors to trigger a safe shutdown if predefined limits are exceeded.
