Triconex 3805E Analog Output Module
Brief Product Description
The Triconex 3805E is a Triple Modular Redundant (TMR) Analog Output (AO) module designed for use in Triconex safety instrumented systems (SIS). It provides 8 isolated output channels, each capable of generating an industry-standard 4–20 mA signal. The module’s TMR architecture ensures exceptional fault tolerance, making it an essential component for critical applications that require precise and reliable control over process variables.
- Product Type: Analog Output (AO) Module
- Signal Type: 4–20 mA
- Configuration: Triple Modular Redundancy (TMR)
- Points: 8, isolated
- Key Feature: Fault-tolerant analog control with high resolution and accuracy.
A Closer Look at the Triconex 3805E
In safety-critical applications, it’s not enough to simply turn things on or off; sometimes, you need precise and reliable control. The Triconex 3805E is designed for exactly this purpose. It is a highly sophisticated analog output device built on the foundation of Triple Modular Redundancy (TMR).
The core of the 3805E‘s strength lies in its TMR architecture. It contains three independent circuits that receive output commands from the system’s main processors. These three circuits then generate an output signal, and the module uses a voting mechanism to ensure the output is based on a consistent, confirmed command. In the event of a fault in one of the circuits, the other two continue to provide the correct output, allowing the system to operate without interruption while a diagnostic alarm is generated. This design provides the ultimate safeguard against single-point failures, ensuring that the module provides error-free, uninterrupted analog control.
The module also features:
- Advanced Diagnostics: Continuous diagnostics monitor the health of each channel, including voltage and current loopback checks. This ensures that a fault in the module or the field wiring is detected immediately, maintaining system integrity.
- High Resolution and Accuracy: With its high-resolution D/A converters, the module provides precise control over devices like control valves and variable speed drives.
- Hot-Swappable: Like other Triconex I/O modules, the 3805E supports hot-swapping, allowing a faulty module to be replaced online without shutting down the entire system, which is invaluable in continuous processes.
Technical Specifications
Application Areas
The Triconex 3805E is used in any industry that requires high-integrity control of a process using an analog signal.
- Process Control: In refineries, petrochemical plants, and power generation facilities, it’s used to precisely control valves, actuators, and other equipment.
- Burner Management Systems (BMS): For controlling fuel flow to a burner in a safe and controlled manner.
- Emergency Shutdown (ESD) Systems: Used to provide a fail-safe signal to a control valve, ensuring a process is safely brought to a shutdown state.
- Critical Machinery Control: For controlling the speed of pumps and motors in applications where a loss of control could lead to a catastrophic event.
