Triconex 3807 Bipolar Analog Output Module
Brief Product Description
The Triconex 3807 is a specialized Triple Modular Redundant (TMR) Bipolar Analog Output (BPAO) module designed for use in Triconex safety instrumented systems (SIS). It provides 4 output channels that generate a bipolar current signal ranging from -60 to 60 mA. This unique capability is essential for applications that require precise, bidirectional control over a process variable. The module’s TMR architecture ensures exceptional fault tolerance, making it a critical component for specialized and highly demanding safety-related control tasks.
- Product Type: Bipolar Analog Output (BPAO) Module
- Signal Type: -60 to 60 mA (Bipolar)
- Configuration: Triple Modular Redundancy (TMR)
- Points: 4, commoned-return
- Key Feature: Bidirectional, high-current analog control for specialized actuators and devices.
A Closer Look at the Triconex 3807
The Triconex 3807 stands out from typical analog output modules by its ability to generate both positive and negative current signals. This is a crucial feature for applications that require bidirectional control, such as moving a valve in two directions from a central neutral position, or controlling the speed and direction of a motor with a single signal.
The core of the 3807‘s strength lies in its Triple Modular Redundancy (TMR) architecture. It contains three independent sets of circuitry that receive output commands from the system’s main processors. These three circuits then generate the output signal, and the module uses a voting mechanism to ensure the output is based on a consistent, confirmed command. In the event of a fault in one of the circuits, the other two continue to provide the correct output, allowing the system to operate without interruption while a diagnostic alarm is generated. This design provides the ultimate safeguard against single-point failures, ensuring that the module provides error-free, uninterrupted analog control.
The module also features:
- Advanced Diagnostics: The module continuously monitors the health of each channel, including voltage loopback diagnostics to verify the output is being generated correctly.
- High Resolution and Accuracy: With its 13-bit resolution, the module provides precise control over its full range of operation.
- Hot-Swappable: Like other Triconex I/O modules, the 3807 supports hot-swapping, allowing a faulty module to be replaced online without shutting down the entire system, which is invaluable in continuous processes.
- Required ETP: The module must be paired with a compatible External Termination Panel (ETP), such as the Triconex 9871-810, to provide a secure and reliable interface for field wiring.
Technical Specifications
Application Areas
The Triconex 3807 is used in highly specialized safety and critical control applications where standard analog outputs are not sufficient.
- Turbomachinery Control: Used to control actuators on turbines and compressors that require a bipolar signal for precise positioning.
- Servo Control: For high-integrity servo applications where the direction and speed of a servo motor or actuator must be controlled with a single, fault-tolerant signal.
- Critical Valve Control: In applications where valves must be precisely positioned both open and closed, a bipolar signal can provide a more robust and reliable control method.
