TRICONEX 4210
⁦TRICONEX 4210⁩ - الصورة ⁦2⁩

TRICONEX 4210

ParameterValue/Description (Typical for TRICONEX 4210 RXM)Module TypeRemote Extender Module (RXM) / Primary SRXMPart Number4210 (often part of a set, e.g., 4210-3 modules)ManufacturerTriconex (Schneider Electric)FunctionExtends Tricon I/O bus, enables remote I/O deployment, signal repeating.Safety Integrity Level (SIL)Contributes to overall system SIL 3 certification (IEC 61508)Cable TypeSingle-mode Fiber OpticMax Cable Length12 kilometers (7.5 miles)Fiber ConnectorsST-interfaceRemote Sites SupportedUp to 3 remote sites per primary RXM setCommunication Rate375 KbpsI/O Bus ExtensionExtends the Tricon I/O bus, allowing I/O modules to be placed remotely.RedundancyOperates in a TMR configuration (typically as a set of three modules).IsolationProvides ground loop isolation.Diagnostic LEDsPASS, FAIL, ACTIVE, TX (Transmit), RX1, RX2, RX3 (Receive for channels A, B, C)Power Consumption(Specific value not readily available, powered from Tricon chassis)Operating TemperatureStandard industrial range (e.g., 0°C to 60°C or -40°C to +70°C for robust industrial use).Storage Temperature-40°C to +85°CHumidity5% to 95% relative humidity, non-condensingDimensionsApproximately 49 cm x 45.3 cm x 6.8 cm (as per one source)WeightApprox. 2.75 kg – 5 kg (depending on packaging and whether it’s a single module or set)MountingPlugs into a Triconex chassis (Primary RXM chassis).CertificationsUL, CE, CSA, FM, TUV (for functional safety), etc. (as part of Triconex system).

احصل على عرض أسعار
التصنيف:

الوصف

The search results indicate that “TRICONEX 4210” is primarily a Remote Extender Module (RXM). It is part of a system that allows I/O modules to be located long distances (up to 12 kilometers) from the main Tricon chassis, typically using single-mode fiber optic cables. Some sources also mention it in the context of being an “Analog Input Module” or even an “Industrial PC”, but the most consistent and detailed information points to its role as an RXM. The mention of “4210-3 module” also supports this, indicating it’s a specific variant within the RXM family (which includes 4200, 4201, 4211).

Given the conflicting information, but strong evidence for RXM, I will prioritize its description as a Remote Extender Module, while acknowledging the other less definitive mentions.

1. Product Name:

TRICONEX 4210 – Remote Extender Module (RXM)

(Note: While some sources might broadly categorize it or a component within it as an Analog Input Module or Industrial PC, its primary and most consistently documented function is as a Remote Extender Module for the Triconex system.)

2. Product Description:

In large-scale industrial facilities, where critical processes span vast geographical areas, the ability to extend the reach of safety control systems without compromising reliability is paramount. The TRICONEX 4210 is a sophisticated Remote Extender Module (RXM) specifically designed to address this challenge within the highly reliable Triconex Safety Instrumented Systems (SIS).

The 4210, often referred to as a Primary SRXM (Single-Mode Remote Extender Module), serves as a crucial repeater and extender of the Tricon I/O bus. Its primary function is to enable Input/Output (I/O) modules to be deployed significant distances (up to 12 kilometers or 7.5 miles) away from the main Tricon chassis. This capability is indispensable in applications such as large-scale chemical plants, oil and gas fields, and power generation facilities, where equipment is widely distributed and remote from the central control room.

The module operates with single-mode fiber optic cables, which provide superior immunity to electromagnetic interference (EMI), ensuring stable and reliable signal transmission over long distances. A key feature of the RXM system, including the 4210, is its Triple Modular Redundancy (TMR) architecture. RXM sets typically consist of three identical modules (e.g., 4210-3 indicates a set of 3 modules), mirroring the TMR design of the core Tricon system. This redundancy ensures that even if one or two channels fail, the system can continue to operate without interruption, maintaining the highest level of safety and availability.

The TRICONEX 4210 plays a vital role in signal relaying and expansion, amplifying signals and extending the transmission distance of the Tricon system’s backplane bus. It supports connectivity to multiple remote sites (up to 3 remote points per primary RXM set), each connected via 6 fiber optic cables (two for each of the A, B, and C channels for data transmission and reception), ensuring reliable data flow for critical control and safety functions.

Key Features:

  • Remote I/O Extension: Enables deployment of Tricon I/O modules up to 12 kilometers (7.5 miles) from the main chassis.
  • Fiber Optic Communication: Utilizes single-mode fiber optic cables for robust, interference-free data transmission.
  • Triple Modular Redundancy (TMR): Incorporates TMR principles to ensure fault tolerance and high availability.
  • Signal Amplification and Extension: Acts as a repeater for the Tricon I/O bus, extending its reach.
  • Multi-Site Support: A primary RXM set can support up to 3 remote locations.
  • Diagnostic Indicators: Features LEDs (PASS, FAIL, ACTIVE, TX, RX1, RX2, RX3) for easy status monitoring.
  • Ground Loop Isolation: Provides isolation to prevent ground loop issues in distributed systems.

3. Product Parameters:

  • Module Type: Remote Extender Module (RXM) / Primary SRXM.
  • Manufacturer: Triconex (Schneider Electric / Invensys).
  • Part Number: 4210 (often part of a set, e.g., 4210-3).
  • Compatibility: Triconex Tricon systems (likely Tricon v9, v10, and subsequent versions).
  • Cable Type: Single-mode fiber optic.
  • Maximum Cable Length: 12 kilometers (7.5 miles).
  • Fiber Optic Connectors: ST-interface optical fibers.
  • Number of Remote Sites Supported: Up to 3 per primary RXM set.
  • Communication Rate: 375 kilobits per second (Kbps).
  • Channels for Data Transmission: Uses 6 fiber optic cables per remote site (2 for each of the A, B, C channels).
  • Diagnostic Indicators: PASS, FAIL, ACTIVE, TX, RX1, RX2, RX3.

4. Specifications:

Parameter Value/Description (Typical for TRICONEX 4210 RXM)
Module Type Remote Extender Module (RXM) / Primary SRXM
Part Number 4210 (often part of a set, e.g., 4210-3 modules)
Manufacturer Triconex (Schneider Electric)
Function Extends Tricon I/O bus, enables remote I/O deployment, signal repeating.
Safety Integrity Level (SIL) Contributes to overall system SIL 3 certification (IEC 61508)
Cable Type Single-mode Fiber Optic
Max Cable Length 12 kilometers (7.5 miles)
Fiber Connectors ST-interface
Remote Sites Supported Up to 3 remote sites per primary RXM set
Communication Rate 375 Kbps
I/O Bus Extension Extends the Tricon I/O bus, allowing I/O modules to be placed remotely.
Redundancy Operates in a TMR configuration (typically as a set of three modules).
Isolation Provides ground loop isolation.
Diagnostic LEDs PASS, FAIL, ACTIVE, TX (Transmit), RX1, RX2, RX3 (Receive for channels A, B, C)
Power Consumption (Specific value not readily available, powered from Tricon chassis)
Operating Temperature Standard industrial range (e.g., 0°C to 60°C or -40°C to +70°C for robust industrial use).
Storage Temperature -40°C to +85°C
Humidity 5% to 95% relative humidity, non-condensing
Dimensions Approximately 49 cm x 45.3 cm x 6.8 cm (as per one source)
Weight Approx. 2.75 kg – 5 kg (depending on packaging and whether it’s a single module or set)
Mounting Plugs into a Triconex chassis (Primary RXM chassis).
Certifications UL, CE, CSA, FM, TUV (for functional safety), etc. (as part of Triconex system).

Important Note: While some sources mention “TRICONEX 4210” in broader contexts (like “Analog Input Module” or “Industrial PC”), the most detailed and consistent information points to its role as a Remote Extender Module within the Triconex SIS architecture. Always refer to official Schneider Electric / Triconex product documentation for the most precise and verified specifications for your specific application.
