Triconex 9764-310 RTD/TC/AI Termination Panel

The Triconex 9764-310 is a specialized External Termination Panel (ETP) designed for use in a Triconex safety instrumented system. It provides a highly versatile and robust wiring interface for an Analog Input module that can handle a variety of sensor types, including Resistance Temperature Detectors (RTD), Thermocouples (TC), and standard Analog Input (AI) signals.

Key Features and Functions

The 9764-310 panel is a critical component for applications that require precise temperature monitoring and a flexible analog input solution. Its main features and functions include:

• Versatile Sensor Support: This panel is specifically engineered to accommodate multiple types of sensors, making it a flexible solution for different industrial applications. It supports both RTDs and thermocouples for temperature measurement, as well as general analog inputs.
• 16 Input Points: The panel provides a wiring interface for 16 distinct analog input points, offering a high-density solution that saves space and simplifies system architecture.
• Signal Conditioning: The panel is equipped with high-quality input signal conditioners from Analog Devices™, ensuring that the raw signals from the sensors are accurately processed and prepared for the Triconex I/O module.
• Compatibility and Power: The panel is designed to be cabled to a specific baseplate, such as the Model 2352 Analog Input External Termination Panel Baseplate. It can receive its +24 VDC power from this baseplate or from a direct connection.
• Simplified and Secure Wiring: The ETP provides a clean, screw-terminal interface for all field wiring. This simplifies installation, reduces the risk of wiring errors, and allows for the easy connection of 2-wire, 3-wire, or 4-wire RTDs. A single, pre-fabricated cable connects the ETP to the I/O module, protecting the sensitive electronics.

Technical Specifications

Application Areas

The Triconex 9764-310 is an integral part of any safety system that requires reliable and high-integrity temperature and analog signal monitoring.

• Emergency Shutdown Systems (ESD): Used to connect a wide range of temperature sensors and analog transmitters for monitoring critical process variables that could trigger a safety shutdown.
• Turbine Control: Provides the wiring interface for monitoring bearing temperatures, exhaust temperatures, and other critical process parameters on gas or steam turbines.
• Fire and Gas Systems (F&G): It can be used to connect analog temperature sensors for fire detection and to monitor gas concentrations.
• General Process Monitoring: In refineries, chemical plants, and other industries, it is used for continuous, high-integrity monitoring of temperatures in reactors, furnaces, and pipelines.
