Product Parameters & Specifications:

General Specifications:

  • Module Type: Digital Input/Output Module
  • Part Number: 9563-830F
  • System Compatibility:
    • Compatible with Triconex Safety Systems such as Tricon, Tricon 3000, and other Triconex controllers.

Digital Input/Output Features:

  • Input Channels:

    • 16 Digital Input Channels
    • Input Type: Suitable for dry contact, wet contact, and voltage-free contact devices such as switches and sensors.
    • Input Voltage: Operates with 24V DC signals.
    • Input Impedance: Optimized for standard industrial field devices.
احصل على عرض أسعار
التصنيف:

الوصف

The Triconex 9563-830F is a digital input/output (I/O) module used in Triconex Safety Systems for industrial automation and safety-critical applications. Below is a detailed overview of the Triconex 9563-830F module:

Product Name:

Triconex 9563-830F I/O Module

Product Description:

The Triconex 9563-830F is a digital input/output module designed for use in Triconex Safety Systems, specifically for Triple Modular Redundancy (TMR) systems, which are widely used in safety-critical industries like oil & gas, chemical processing, power generation, and other industries requiring high reliability and safety standards. This module allows for the integration of field devices (such as sensors, switches, and actuators) with the Triconex control system, providing real-time control and monitoring in hazardous environments.

The module offers 16 digital input channels and 16 digital output channels, each capable of handling 24V DC signals. It is built to meet Safety Integrity Level (SIL) requirements, ensuring that it can be safely used in Safety Instrumented Systems (SIS), Emergency Shutdown Systems (ESD), and other critical applications. It also features galvanic isolation between inputs and outputs, minimizing the risk of electrical faults and enhancing safety and reliability.

Product Parameters & Specifications:

General Specifications:

  • Module Type: Digital Input/Output Module
  • Part Number: 9563-830F
  • System Compatibility:
    • Compatible with Triconex Safety Systems such as Tricon, Tricon 3000, and other Triconex controllers.

Digital Input/Output Features:

  • Input Channels:

    • 16 Digital Input Channels
    • Input Type: Suitable for dry contact, wet contact, and voltage-free contact devices such as switches and sensors.
    • Input Voltage: Operates with 24V DC signals.
    • Input Impedance: Optimized for standard industrial field devices.

  • Output Channels:

    • 16 Digital Output Channels
    • Output Type: Open collector outputs, ideal for controlling relays, solenoids, and other actuators.
    • Output Voltage: 24V DC for compatibility with most industrial control systems.
    • Output Load Capacity: Each output channel typically supports 1A current.

Electrical & Environmental Specifications:

  • Power Supply:

    • Powered by the Triconex control system, requiring 24V DC power.

  • Power Consumption:

    • Typically consumes 6W of power.

  • Operating Temperature Range:

    • 0°C to 60°C (32°F to 140°F), designed for standard industrial environments.

  • Storage Temperature:

    • -40°C to 85°C (-40°F to 185°F), suitable for safe storage under varying conditions.

  • Humidity:

    • 5% to 95% relative humidity, non-condensing, ensuring reliable operation in humid environments.

  • Protection Rating:

    • IP20 protection, suitable for use in control cabinets or enclosed environments.

Safety & Compliance:

  • Safety Integrity:

    • The module is designed to meet SIL (Safety Integrity Level) standards, ensuring it is safe to use in Safety Instrumented Systems (SIS) and critical safety functions.

  • Certification:

    • Compliant with UL, CSA, and CE standards, ensuring global certification for quality and safety.

Mounting and Installation:

  • Mounting:
    • The 9563-830F is mounted in a 19-inch rack as part of the Triconex system architecture.
  • Size:
    • Compact and modular design, ensuring easy installation and integration into existing control systems.

Communication and Integration:

  • Backplane Communication:

    • The module communicates via the Triconex system’s backplane, enabling high-speed data exchange between modules and the central processor (CPU).

  • Field Communication:

    • Inputs and outputs are connected to field devices for real-time monitoring and control.

Key Features:

  1. 16 Digital I/O Channels:

    • 16 digital input channels and 16 digital output channels for comprehensive control and monitoring.

  2. 24V DC Signals:

    • Supports 24V DC signals, compatible with most industrial field devices.

  3. Triple Modular Redundancy (TMR):

    • Provides high availability and fault tolerance, ensuring system reliability in critical applications.

  4. Galvanic Isolation:

    • Isolates inputs and outputs to protect the system from electrical faults and noise.

  5. SIL Certification:

    • Designed to meet Safety Integrity Level (SIL) standards, ensuring the module is suitable for safety-critical applications.

  6. Industrial Certifications:

    • UL, CSA, and CE certified, ensuring compliance with international industrial safety standards.

  7. Wide Temperature Range:

    • Suitable for use in environments ranging from 0°C to 60°C during operation, with a wider storage range of -40°C to 85°C.

  8. Compact Design:

    • Fits into standard 19-inch racks, allowing for flexible integration and expansion.

Applications:

The Triconex 9563-830F module is used in various industries for safety-critical applications, including:

  • Oil & Gas: For controlling and monitoring critical systems in upstream, midstream, and downstream operations.
  • Chemical & Petrochemical: Used in Safety Instrumented Systems (SIS), Emergency Shutdown Systems (ESD), and process monitoring.
  • Power Generation: Ensures the safe operation of turbines, boilers, and other power plant equipment.
  • Refining: Used to monitor and control safety-critical systems in refinery operations.
  • Manufacturing: Applicable in any safety-critical automated manufacturing environment, ensuring safety and reliability.

How to Find More Information:

For further details, such as installation guides, manuals, and troubleshooting information, refer to the official Schneider Electric/Triconex documentation or contact their technical support team for assistance.

If you need more details or specific guidance on integrating the Triconex 9563-830F module into your control system, feel free to ask! 3BSE031151R1 I/O
