Triconex+9664-130F

الوصف

The Triconex 9664-130F is a high-reliability Programmable Logic Controller (PLC) module designed as part of the Triconex Safety Instrumented Systems (SIS), ideal for use in safety-critical applications that require Triple Modular Redundancy (TMR) and meet the highest safety standards like SIL 3 (Safety Integrity Level 3). Below is a detailed description of this module, including product name, description, parameters, and specifications:

Product Name:

Triconex 9664-130F PLC Module

Product Description:

The Triconex 9664-130F is a Programmable Logic Controller (PLC) module designed for use within Triconex safety systems, particularly suited for applications in oil & gas, chemical processing, power generation, and other industries requiring stringent safety standards. It is an integral part of the Triconex system, providing Triple Modular Redundancy (TMR) to ensure safety-critical systems remain operational even if a component fails.

The module features a redundant architecture designed for fault tolerance, with self-diagnostic functions, electrical isolation, and redundant power supplies, offering robust performance for SIL 3 rated safety applications. The 9664-130F is widely used in Emergency Shutdown (ESD) systems, fire & gas systems, and process automation systems where continuous, reliable operation is crucial for preventing hazardous conditions.

Product Parameters & Specifications:

General Information:

• Module Type: Programmable Logic Controller (PLC)
• Part Number: 9664-130F
• Form Factor: Fits into Triconex control systems like Tricon 3000.
• Compatibility: Integrated with the Triconex TMR system.

Key Features:

1. Triple Modular Redundancy (TMR):

   • Uses three redundant channels to ensure continuous operation in case of failure, significantly reducing the risk of system downtime in safety-critical operations.

2. SIL 3 Compliance:

   • The 9664-130F meets SIL 3 safety standards, providing high reliability and fault tolerance for industrial processes where safety is paramount.

3. Redundant Power Supplies:

   • The module includes dual power supplies, ensuring that the system continues to function even in the event of a power failure in one of the supply channels.

4. Galvanic Isolation:

   • Designed with electrical isolation between input and output circuits, which enhances reliability and protects against electrical interference.

5. Self-Diagnostics:

   • The module includes built-in self-diagnostic features, which constantly monitor the system’s health and functionality to preemptively detect and report faults.

6. Redundant I/O:

   • The module offers redundant input and output channels to enhance system reliability and support critical safety functions.

Input/Output Specifications:

• Digital Inputs:

  • Input Voltage: Typically 24V DC.
  • Input Type: Digital inputs used for collecting signals from sensors, switches, or other field devices.

• Digital Outputs:

  • Output Type: Open collector output (or similar).
  • Output Voltage: Usually 24V DC.
  • The outputs control field devices such as actuators, solenoids, and valves.

• Output Protection:

  • The module includes built-in protection circuits to prevent damage to field devices from electrical faults or surges.

• Isolation:

  • Each I/O channel is galvanically isolated, providing better protection against electrical noise, and reducing the risk of ground loops.

Electrical & Environmental Specifications:

• Power Supply:

  • The module requires a 24V DC power supply.

• Power Consumption:

  • Typical consumption is between 10W to 20W, depending on the specific configuration and operating conditions.

• Operating Temperature:

  • The module operates in an environmental temperature range from 0°C to 60°C (32°F to 140°F).

• Storage Temperature:

  • The unit can be stored in a temperature range from -40°C to 85°C (-40°F to 185°F).

• Humidity:

  • Operates in environments with 5% to 95% relative humidity (non-condensing).

• Protection Class:

  • The IP20 protection rating makes it suitable for installation in enclosed control panels or cabinets.

• Mounting:

  • Designed for mounting in 19-inch racks or compatible systems, providing flexibility for system installation.

Safety Certifications & Compliance:

• Safety Integrity Level (SIL):

  • SIL 3 certification for high safety performance in safety-critical applications.

• Certifications:

  • The module meets global safety standards, including UL, CSA, and CE certifications, as well as compliance with industry-specific standards such as IEC 61508 and IEC 61511 for safety instrumented systems.

• International Standards:

  • The 9664-130F complies with ISO 13849 for safety systems, as well as additional process safety standards, making it applicable for industries with strict regulatory requirements.

Communication and Integration:

• Backplane Communication:

  • The module communicates via the Triconex backplane, allowing seamless integration with other modules in the Triconex system.

• Fieldbus Communication:

  • Supports industry-standard fieldbus protocols for communication with field devices, enabling broad compatibility across different platforms and devices.

• Redundant Network:

  • The system supports redundant communication paths, ensuring fault tolerance in case of network failure.

Typical Applications:

The Triconex 9664-130F PLC module is ideal for safety-critical operations in industries where uptime and reliability are essential. Common applications include:

1. Oil & Gas:

   • Used in Emergency Shutdown (ESD) systems, fire & gas detection, and process control for upstream, midstream, and downstream operations.

2. Chemical and Petrochemical:

   • Applied in hazardous chemical processes to control reactors, manage burner management systems (BMS), and monitor emergency shutdowns.

3. Power Generation:

   • Protects boilers, turbines, and generators by monitoring safety-critical functions and preventing failures.

4. Refining:

   • Used in refinery operations to monitor safety, such as controlling pressure, temperature, and other vital processes.

5. Pharmaceutical & Manufacturing:

   • Ensures continuous, safe operation in manufacturing plants where failures can lead to hazardous conditions or production stoppages.

Summary of Key Features:

• Triple Modular Redundancy (TMR) ensures fault tolerance.
• SIL 3 Certification for high safety performance.
• Redundant power supplies for uninterrupted operation.
• Galvanic isolation to avoid electrical interference.
• Built-in self-diagnostics for proactive maintenance.
• IP20 protection for safe installation.
• Global certifications (UL, CSA, CE).

If you need further details or have specific questions about the Triconex 9664-130F module, feel free to ask! 3BDH001010R0001
