Triconex+9761-230F

الوصف

The Triconex 9761-230F module is a digital input/output module designed for use in Triconex safety systems and Tricon systems used in industrial automation, process control, and safety-critical applications. Below is a detailed breakdown of the module, including its product name, description, and specifications.

Product Name:

Triconex 9761-230F Digital Input/Output Module

Product Description:

The Triconex 9761-230F is a digital I/O module for the Triconex Safety System, which is widely used in critical safety and process control applications, particularly in industries such as oil & gas, chemical plants, power generation, and refining. This module enables the safe and reliable interaction between the Triconex safety system controller and field devices like sensors, actuators, switches, and valves.

The 9761-230F module integrates seamlessly with Triconex’s Triple Modular Redundancy (TMR) architecture, providing a highly reliable, fault-tolerant solution that is essential for safety-critical operations. This module specifically provides digital inputs and digital outputs for real-time control and feedback within the safety system.

Product Parameters & Specifications:

General Specifications:

• Module Type: Digital Input/Output Module
• Part Number: 9761-230F
• System Compatibility:
  • Compatible with Triconex Safety Systems such as Tricon, Tricon 3000, and other systems within the Triconex family.

Digital Input/Output Features:

• Input Channels: The module typically provides 16 digital input channels.

  • Input Voltage: 24V DC (commonly used in industrial applications).
  • Signal Type: Dry contact, voltage-free contacts, or wet contact inputs.
  • Input Type: Can accept digital signals from field devices like switches, sensors, and other binary devices.

• Output Channels: The module typically provides 16 digital output channels.

  • Output Voltage: 24V DC, which is the industry standard for controlling relays, solenoids, and other actuators.
  • Output Type: Open collector, capable of driving external devices like relays or solenoids.
  • Output Load Capacity: Each output channel can typically handle up to 1A, depending on the application and installation.

• Relay Outputs: In some cases, the module may feature relay outputs (Form C relays), which are useful for controlling large inductive loads.

Electrical & Environmental Specifications:

• Power Supply:

  • Typically powered by the Triconex system, requiring 24V DC for proper operation.

• Power Consumption:

  • Relatively low power consumption, usually around 5W per module.

• Operating Temperature Range:

  • 0°C to 60°C (32°F to 140°F), suitable for most industrial environments.

• Storage Temperature:

  • -40°C to 85°C (-40°F to 185°F), ensuring safe storage under a wide range of conditions.

• Humidity:

  • Rated for 5% to 95% relative humidity, non-condensing.

• Protection Rating:

  • IP20 protection (for use in control cabinets or other protected environments).

• Isolation:

  • Galvanic isolation for both inputs and outputs, providing protection from electrical faults.

Safety & Compliance:

• Safety Integrity:

  • The Triconex 9761-230F module is designed to meet SIL (Safety Integrity Level) standards, ensuring high safety integrity for critical control applications.

• Certification:

  • The module is typically UL, CSA, and CE certified, ensuring compliance with international safety and quality standards.

Mounting and Installation:

• Mounting:

  • Typically mounted on a rack within the Triconex system.
  • Form Factor: The module has a compact design, fitting into a standard 19-inch rack for easy integration into control systems.

• Size:

  • Compact and modular, designed to fit easily into the Triconex system’s rack for easy expansion.

Communication and Integration:

• Bus Communication:

  • Integrates into the Triconex system through the system’s proprietary backplane and communication architecture.

• Field Communication:

  • The digital I/O signals are transmitted via the Triconex backplane, with high-speed communication between the module and the central processing unit of the safety system.

Key Features:

1. 16 Digital I/O Channels: Provides a high density of I/O for field devices such as switches, sensors, relays, and actuators.

2. 24V DC Input/Output Signals: Compatible with standard industrial field devices that use 24V DC for control and feedback.

3. Reliability and Redundancy: Supports Triple Modular Redundancy (TMR) for high reliability and fault tolerance, which is essential for safety systems in critical industrial applications.

4. Galvanic Isolation: Provides protection from electrical faults with isolated inputs and outputs.

5. Safety-Critical Applications: Meets SIL standards, making it suitable for safety-critical applications such as emergency shutdown systems, process safety monitoring, and burner management systems.

6. Certified: The module complies with major safety and quality standards such as UL, CSA, and CE.

7. Compact and Modular Design: Easily integrates into Triconex system racks and can be expanded as part of a larger safety or control system.

8. Temperature Tolerance: Designed to operate in harsh industrial environments with a wide temperature operating range of 0°C to 60°C.

Applications:

• Oil & Gas: Provides reliable control and safety monitoring for production facilities, offshore platforms, and refineries.
• Chemical Plants: Used to control and monitor critical safety processes, such as emergency shutdown (ESD) systems and safety instrumented systems (SIS).
• Power Generation: Ensures safe operation of power plants by controlling turbine generators, fuel systems, and boiler controls.
• Refineries: Used in safety-critical applications like flare systems, leak detection, and emergency shutdown systems.
• Manufacturing & Industrial Automation: Applied to general industrial automation needs, particularly in process industries.

How to Find More Information:

For additional technical details, documentation, installation guides, and troubleshooting support, it’s best to refer to Schneider Electric (which owns Triconex) or consult the Triconex System manuals.
