The Triconex TCM 4355X is a Distributed Control System (DCS) module designed by Triconex, a leading provider of safety and control systems. Part of the Tricon™ Safety System family, the TCM 4355X is specifically designed for high-performance applications requiring high availability, high reliability, and advanced process control. This module is typically used in industries such as oil & gas, chemical manufacturing, power generation, and refining, where safety and precision are critical.

The TCM 4355X module is part of the Triconex 4350 series, designed for fault-tolerant, safety-critical applications. Its robust architecture ensures system redundancy, preventing single points of failure in mission-critical control and monitoring tasks. The TCM 4355X supports True Triple Modular Redundancy (TMR), a key feature that enhances system availability and provides real-time diagnostics to ensure the smooth running of industrial processes.

Product Parameters & Specifications:

General Specifications:

  • Model: Triconex TCM 4355X
  • Type: DCS (Distributed Control System) PLC Module
  • Series: Tricon™ Safety System
  • Functionality:
    • Designed for safety-critical applications requiring high reliability, redundancy, and fault tolerance.
    • Provides advanced process control, monitoring, and safety protection for complex industrial systems.
    • Supports True Triple Modular Redundancy (TMR), which ensures high availability and fault tolerance.
احصل على عرض أسعار
التصنيف:

الوصف

Product Name:

Triconex TCM 4355X DCS PLC Module

Product Description:

The Triconex TCM 4355X is a Distributed Control System (DCS) module designed by Triconex, a leading provider of safety and control systems. Part of the Tricon™ Safety System family, the TCM 4355X is specifically designed for high-performance applications requiring high availability, high reliability, and advanced process control. This module is typically used in industries such as oil & gas, chemical manufacturing, power generation, and refining, where safety and precision are critical.

The TCM 4355X module is part of the Triconex 4350 series, designed for fault-tolerant, safety-critical applications. Its robust architecture ensures system redundancy, preventing single points of failure in mission-critical control and monitoring tasks. The TCM 4355X supports True Triple Modular Redundancy (TMR), a key feature that enhances system availability and provides real-time diagnostics to ensure the smooth running of industrial processes.

Product Parameters & Specifications:

General Specifications:

  • Model: Triconex TCM 4355X
  • Type: DCS (Distributed Control System) PLC Module
  • Series: Tricon™ Safety System
  • Functionality:
    • Designed for safety-critical applications requiring high reliability, redundancy, and fault tolerance.
    • Provides advanced process control, monitoring, and safety protection for complex industrial systems.
    • Supports True Triple Modular Redundancy (TMR), which ensures high availability and fault tolerance.

Key Features:

  • True Triple Modular Redundancy (TMR): Ensures that the system can tolerate the failure of any individual component (processor, I/O, or power supply) without affecting overall system performance.
  • Fault-Tolerant: Built-in fault tolerance to guarantee continuous operation even in the event of a failure in any part of the system.
  • High Availability: Offers excellent uptime with redundant power supplies, processor modules, and I/O configurations.
  • Real-time Diagnostics: Supports continuous monitoring and diagnostics to detect and report potential system issues before they affect operations.
  • Safety Standards Compliance: Meets rigorous safety and reliability standards, making it ideal for safety-critical applications in industries like oil & gas, petrochemical, power generation, and more.

Electrical Specifications:

  • Power Supply:
    • Typically operates with a 24V DC power supply.
    • Redundant power supplies for increased reliability and system uptime.
  • Power Consumption:
    • Low power consumption designed for continuous, 24/7 operation in industrial settings.
  • Input Voltage Range:
    • Typically 24V DC with wide tolerance to accommodate various industrial environments.
  • Communication:
    • Supports serial communication over RS-485 and Modbus for seamless integration with control systems and other modules.
    • Ethernet connectivity for remote monitoring and integration with higher-level systems like SCADA or DCS.

Mechanical Specifications:

  • Form Factor:

    • Modular design for rack-mounted installation in a 19-inch standard rack.
    • Typically fits into an I/O rack as part of the Triconex system architecture.

  • Dimensions:

    • Standard dimensions for a module in the Triconex 4350 series, typically height: 3U and depth: ~200mm.
    • Exact dimensions may vary depending on the system configuration and installation.

  • Cooling:

    • Passive cooling design with proper ventilation required to ensure proper system heat dissipation.

  • Weight:

    • Approximately 2-3 kg depending on the configuration and exact components installed.

Environmental Specifications:

  • Operating Temperature:

    • Typically -20°C to +60°C (extended temperature ranges may be available for harsh environments).

  • Storage Temperature:

    • -40°C to +85°C to support industrial applications and transportation in various environments.

  • Relative Humidity:

    • Typically rated for 5% to 95% non-condensing humidity levels, making it suitable for harsh industrial environments.

  • Vibration and Shock Resistance:

    • Designed to meet industrial vibration and shock standards, ensuring reliability in challenging environments.

  • Ingress Protection:

    • Typically installed in an IP20-rated enclosure for protection against dust and accidental contact.

Functional Specifications:

  • I/O Support:

    • Supports a wide range of digital and analog I/O modules for flexible configuration in various industrial applications.
    • Modular I/O design allows users to configure the system to meet specific process control needs.

  • Redundancy:

    • Fully redundant architecture with multiple processor modules, power supplies, and communication paths to ensure high availability and safety.
    • Redundant network connections for increased fault tolerance.

  • Safety and Fault Detection:

    • Built for safety-critical applications with built-in fault detection capabilities to prevent dangerous conditions in case of hardware failure.
    • Provides automated failover mechanisms to maintain operation during faults.

  • Real-time Monitoring and Diagnostics:

    • Continuous real-time monitoring and diagnostics capabilities for system health, making it easy to identify potential issues early.
    • Built-in event logging and fault recording features for troubleshooting and maintenance.

Software and Configuration:

  • Triconex Configuration Software:

    • Configured using Triconex’s proprietary software tools, such as TriStation™ for system setup, configuration, and maintenance.
    • Supports Graphical User Interface (GUI) for easy programming and configuration.

  • Diagnostics and Monitoring:

    • Integrated diagnostics to identify faults within the system, helping operators quickly address any issues.
    • The system can be monitored and controlled via remote SCADA systems or other HMI devices.

Applications:

  • Oil & Gas:

    • Used in upstream and downstream applications for safe control and monitoring of wellheads, pipelines, refineries, and processing plants.

  • Power Generation:

    • Ideal for critical control and monitoring of power plants, turbines, and other vital energy infrastructure.

  • Chemical and Petrochemical:

    • Suitable for process control in hazardous environments such as refineries, chemical plants, and distribution systems.

  • Manufacturing and Industrial Automation:

    • Employed in various manufacturing and industrial processes where precision control, high availability, and fault tolerance are essential.

  • Safety-Critical Systems:

    • Often used in safety applications like emergency shutdown systems (ESD) and process safety management (PSM).

Conclusion:

The Triconex TCM 4355X DCS PLC Module provides exceptional reliability, fault tolerance, and performance for safety-critical applications in industries such as oil & gas, power generation, and chemical processing. Its True Triple Modular Redundancy (TMR) ensures that the system is always available, even in the event of a hardware failure. With real-time diagnostics, redundancy in all critical components, and compliance with industry safety standards, the TCM 4355X is a cornerstone of high-reliability industrial control systems.
