Name: WOODWARD 5466-5006 - RUNSHENG
Price: 8888.00 CNY
Availability: InStock

الوصف

The WOODWARD 5466-5006 is a crucial communication module within Woodward’s industrial control systems. It’s identified as a MicroNet SIO (Serial I/O) Module with Screw Posts.

This module is designed to provide additional serial communication ports to a MicroNet Plus digital control system, allowing it to interface with various third-party devices that communicate via serial protocols (like RS-232, RS-422, or RS-485).

1. SEO-Optimized Titles:

WOODWARD 5466-5006: MicroNet Plus SIO Module with Screw Posts.
WOODWARD 5466-5006: Serial I/O Expansion for Woodward MicroNet Plus.
WOODWARD 5466-5006: Industrial RS-232/RS-422/RS-485 Communication Module.
WOODWARD 5466-5006: Woodward MicroNet Plus Serial Interface.
WOODWARD 5466-5006: SIO Module for Third-Party Device Integration.
WOODWARD 5466-5006: Smart-Plus Architecture Serial I/O.
WOODWARD 5466-5006: Woodward Module for SCADA/HMI Serial Connectivity.
WOODWARD 5466-5006: High-Performance Serial Communication for Turbines.
WOODWARD 5466-5006: MicroNet Digital Control SIO Module.

2. Product Overview:

The WOODWARD 5466-5006 is a Serial I/O (SIO) Module specifically designed for the Woodward MicroNet Plus digital control platform. It provides additional serial communication ports (typically two RS-232 and two configurable RS-232/RS-422/RS-485 ports), allowing the MicroNet Plus controller to interface with external devices such as vibration monitoring systems, HMIs, or other third-party equipment that utilize serial communication protocols. This particular variant features screw posts for field wiring termination.

Product Type: Serial I/O (SIO) Module
Manufacturer: Woodward
Series: MicroNet Plus
Function: Adds serial communication ports (RS-232, RS-422, RS-485) to the MicroNet Plus system.
Key Feature: Screw post terminals for wiring.

3. Detailed Product Description:

In many industrial control applications, the central controller needs to communicate with a variety of external devices that rely on serial communication. The WOODWARD 5466-5006 is specifically designed to meet this need within the Woodward MicroNet Plus system, providing a flexible and robust serial interface.

The 5466-5006 is a Serial I/O (SIO) Module. It allows your MicroNet Plus controller to expand its communication capabilities by adding multiple serial ports. These ports can be configured for different protocols:

Typically, two ports are dedicated RS-232.
Two additional ports are configurable, meaning they can be set up for RS-232, RS-422, or RS-485, offering great flexibility for connecting to various types of equipment.

This module is part of Woodward’s newer “Smart-Plus” architecture, which indicates it’s optimized for use with current-generation CPUs like the 5200 and P1020 CPUs within the MicroNet Plus family. It requires Coder 4.06 or later for programming and configuration.

A key benefit of the 5466-5006 is its “drop-in” backward compatibility for MicroNet Plus systems. This means it can often replace older SIO modules (like 5501-471 or 5466-348) without requiring changes to the existing GAP (Graphical Application Programmer) blocks in your control logic. This makes upgrades and replacements smoother and more efficient.

The “with Screw Posts” in its name signifies the type of field wiring termination. This means wires are securely fastened to the module using screws, a common and robust method for industrial applications. (The 5466-5007 is a similar module but with slide lock terminations).

Key Features and Benefits:

Expanded Serial Communication: Adds multiple serial ports to the MicroNet Plus system, enabling communication with a wide array of third-party devices.
Configurable Ports: Features ports that can be set for RS-232, RS-422, or RS-485, providing versatility to match different device requirements.
Screw Post Terminations: Offers a secure and reliable wiring method for field connections.
“Smart-Plus” Architecture: Optimized for use with newer MicroNet Plus CPUs (5200 and P1020), ensuring high performance and compatibility.
Backward Compatibility: Designed to be “drop-in” compatible with existing MicroNet Plus systems and GAP blocks, simplifying upgrades.
Robust Industrial Design: Built to withstand demanding industrial environments, ensuring long-term reliability.
Diagnostic Capabilities: As with most Woodward modules, it includes internal diagnostics to monitor its health and aid in troubleshooting.

Technical Specifications:

Parameter	Value
Product Type	Serial I/O (SIO) Module
Manufacturer	Woodward
Series	MicroNet Plus
Part Number	5466-5006
I/O Type	Serial Communication
Serial Ports	Typically 4 channels (2 x RS-232, 2 x configurable RS-232/RS-422/RS-485)
Termination Type	Screw Posts
Architecture	“Smart-Plus” Architecture
CPU Compatibility	Optimized for MicroNet Plus 5200 and P1020 CPUs
Software Compatibility	Requires Woodward Coder 4.06 or later
Usage Restriction	Only for use in MicroNet Plus systems; not qualified for MicroNet TMR.
Typical Use	Connecting to vibration monitoring systems, HMIs, other serial devices

Typical Applications:

The WOODWARD 5466-5006 is used in industrial applications where a MicroNet Plus system needs to communicate with external devices via serial interfaces.

Turbine and Compressor Control: Interfacing with vibration monitoring systems, annunciators, or specialized diagnostic tools that use serial communication.
Power Generation: Connecting to auxiliary plant equipment or older DCS (Distributed Control System) components that rely on serial links.
Oil and Gas Industry: Integrating with specialized metering systems, flow computers, or other field devices that use RS-232/422/485.
Any Industrial Automation: Where a MicroNet Plus controller needs to send or receive data from third-party serial devices not natively supported by standard Ethernet or CAN networks.
