The GE IC754VSI06STD is a discontinued Human-Machine Interface (HMI) from the QuickPanel View product family. It’s an operator panel that provides a centralized point for monitoring and controlling industrial processes.



Key Features



  • Display: It features a 6-inch color STN LCD touchscreen with a resolution of 320 x 240 pixels.
  • Processor and Memory: The HMI is powered by a 300 MHz Intel XScale PXA255 processor. It includes 32 MB of Flash memory and 32 MB of DRAM. It also has 512 KB of battery-backed SRAM, which helps retain data even during a power outage.
  • Communication: The IC754VSI06STD is equipped with a variety of communication interfaces:
    • Serial Ports: One combo port that supports RS-232, RS-422, and RS-485 communication.
    • Ethernet: A single Ethernet port (10/100 Mbps) for networking.
  • Software: It runs on the Windows CE operating system and comes pre-loaded with Proficy View Machine Edition for application development and runtime.
  • Physical & Environmental: The unit is designed for panel mounting and is rated for NEMA 4, 4x, and 12 (IP65), which provides protection from dust and water.
