The GE part number IS200EBKPG1C is an EX2100 Control Backplane Card. The “OBS” in the description means it’s obsolete. Its primary function is to serve as the main communication and power distribution hub for all the circuit boards and modules that are installed in the control rack of an EX2100 Excitation Control System.
Function and Key Features
A backplane is a large circuit board with multiple slots or connectors. It acts as the backbone of a modular electronic system, providing the necessary infrastructure for all the other components to function together.
- Communication Bus: The backplane provides a parallel communication bus that allows the different cards in the rack to talk to each other. This includes communication between the main processor (like a DSPX card), the I/O boards, and other specialized modules.
- Power Distribution: It distributes power from the system’s power supply to all the individual boards in the rack, ensuring each board receives the correct voltage.
- Mechanical and Electrical Interface: The card provides the physical interface for mounting and connecting the various modules. Its sturdy design ensures that the boards are held securely in place and that the electrical connections are reliable.
- System Integration: The backplane is a passive component that facilitates the interaction of all the active components, forming the foundation of the EX2100 control rack.
Applications
The IS200EBKPG1C is a legacy component primarily found in older power generation facilities that still operate the EX2100 system. It’s an essential component for:
- Generator Control Systems: It forms the basis of the control cabinet for the EX2100 excitation system, which regulates a generator’s output voltage.
- Reliability and Maintenance: By providing a robust and organized platform, it simplifies maintenance and troubleshooting for the entire control system.
