The GE IS200STAIH2A is a Simplex Analog Terminal Board for the GE Mark VIe (MKVIe) turbine control system. Its main function is to provide a dedicated, non-redundant interface for analog signals from field devices.
Function and Purpose ⚙️
The IS200STAIH2A serves as the crucial interface between the turbine’s analog sensors (such as thermocouples and pressure transmitters) and the main control processor. It receives continuous, or analog, signals and routes them to the system’s I/O packs. The “Simplex” designation indicates that this board is used in applications where a single, non-redundant channel for analog signal measurement is sufficient. It provides a secure termination point for the wiring, which simplifies installation and maintenance. The board also helps to ensure signal integrity by providing a clean path from the field to the sensitive electronics.
Related Components
The IS200STAIH2A works in conjunction with other components of the Mark VIe system, including:
- Processor Cards: The main CPU of the system, which reads the digitized data from the IS200STAIH2A.
- I/O Packs: These electronic modules mount directly on the terminal board and contain the active electronics for signal processing and conversion.
- Analog Field Devices: The board connects to a variety of analog sensors, such as pressure transmitters and thermocouples, to acquire the necessary data.
