GE IS420ESWBH3A

The IS420ESWBH3A switch is built to handle the demanding communication needs of a distributed control system. Its main job is to connect multiple I/O packs and controllers, ensuring fast and reliable data exchange over the proprietary IONet.

  • Ports: This model is a 16-port switch. It has sixteen 10/100Base-TX RJ45 copper ports for standard Ethernet connections. A key feature of the H3A version is that it has no fiber optic ports, differentiating it from other IS420ESWB models.
  • Redundancy: The module features dual power supply inputs that are Diode-OR’d, providing power redundancy. This means the switch can stay operational even if one power source fails.
  • Performance: It is designed for industrial networks and supports both 10 Mbps and 100 Mbps Ethernet speeds. It includes a minimum 256 KB buffer and can handle up to 4K MAC addresses, ensuring efficient data flow.
  • Mounting: The switch is a DIN-rail mountable module, which allows for quick and secure installation in a control cabinet. It can also be panel-mounted with the proper clips.
احصل على عرض أسعار
التصنيف:

الوصف

The GE IS420ESWBH3A is a 16-Port Ethernet IONet Switch used in the GE Mark VIe and Mark VIeS control systems. It is a vital networking component designed for real-time industrial applications, like those found in power generation and heavy machinery.



Key Features and Functionality



The IS420ESWBH3A switch is built to handle the demanding communication needs of a distributed control system. Its main job is to connect multiple I/O packs and controllers, ensuring fast and reliable data exchange over the proprietary IONet.

  • Ports: This model is a 16-port switch. It has sixteen 10/100Base-TX RJ45 copper ports for standard Ethernet connections. A key feature of the H3A version is that it has no fiber optic ports, differentiating it from other IS420ESWB models.
  • Redundancy: The module features dual power supply inputs that are Diode-OR’d, providing power redundancy. This means the switch can stay operational even if one power source fails.
  • Performance: It is designed for industrial networks and supports both 10 Mbps and 100 Mbps Ethernet speeds. It includes a minimum 256 KB buffer and can handle up to 4K MAC addresses, ensuring efficient data flow.
  • Mounting: The switch is a DIN-rail mountable module, which allows for quick and secure installation in a control cabinet. It can also be panel-mounted with the proper clips.
