Keba Erc 64/1-C Robot Pendent- Keba Ht2 Ss A/20677/19 FEN008747
⁦Keba Erc 64/1-C Robot Pendent- Keba Ht2 Ss A/20677/19 FEN008747⁩ - الصورة ⁦2⁩

Keba Erc 64/1-C Robot Pendent- Keba Ht2 Ss A/20677/19 FEN008747

  • Model: KEBA ERC 64/1-C Robot Pendant
  • Manufacturer: KEBA
  • Part Number: KEBA HT2 SS A/20677/19 (FEN008747)
  • Application: Used for robot control in industrial automation environments.
  • System Integration: Integrates with KEBA DCS or PLC systems for real-time control and monitoring of robotic systems.

Display and HMI Features:

  • Display:
    • Type: TFT (Thin-Film Transistor) display for high-resolution graphics and easy visualization.
    • Size: Typically 7” to 12”, depending on configuration.
    • Resolution: 800 x 600 pixels or higher, allowing clear visual representation of robot data, status, and diagnostics.
  • Backlighting:
    • LED or CCFL backlighting for bright and energy-efficient display performance.
  • Touchscreen/Control Interface:
    • Touchscreen for intuitive control, allowing operators to interact directly with the robot system.
    • Keypad and Buttons: Hardware buttons for manual control and emergency stop.
  • Control Elements:
    • Joystick or analog controls for fine-tuning robot movements.
    • Emergency Stop Button for safety during operation.
احصل على عرض أسعار
التصنيف:

الوصف

Product Name:

KEBA ERC 64/1-C Robot Pendant – KEBA HT2 SS A/20677/19 FEN008747 DCS PLC Module

Product Description:

The KEBA ERC 64/1-C Robot Pendant, identified by the KEBA HT2 SS A/20677/19 FEN008747, is a human-machine interface (HMI) specifically designed for robot control applications. This pendant is a part of KEBA’s advanced industrial automation systems, providing a highly intuitive and durable interface for robot operators to manage and control robotic systems.

This robot pendant is typically used in conjunction with the KEBA DCS (Distributed Control System) or PLC (Programmable Logic Controller) systems, enabling seamless communication and control over complex robot operations in industrial environments.

The pendant features a high-performance display, user-friendly control buttons, and rugged construction, making it suitable for heavy-duty industrial environments. With robust communication protocols, the pendant can control robots from a KEBA-based automation system, providing an efficient, safe, and user-friendly interface for robot programming, monitoring, and diagnostics.

Product Parameters & Specifications:

General Specifications:

  • Model: KEBA ERC 64/1-C Robot Pendant
  • Manufacturer: KEBA
  • Part Number: KEBA HT2 SS A/20677/19 (FEN008747)
  • Application: Used for robot control in industrial automation environments.
  • System Integration: Integrates with KEBA DCS or PLC systems for real-time control and monitoring of robotic systems.

Display and HMI Features:

  • Display:
    • Type: TFT (Thin-Film Transistor) display for high-resolution graphics and easy visualization.
    • Size: Typically 7” to 12”, depending on configuration.
    • Resolution: 800 x 600 pixels or higher, allowing clear visual representation of robot data, status, and diagnostics.
  • Backlighting:
    • LED or CCFL backlighting for bright and energy-efficient display performance.
  • Touchscreen/Control Interface:
    • Touchscreen for intuitive control, allowing operators to interact directly with the robot system.
    • Keypad and Buttons: Hardware buttons for manual control and emergency stop.
  • Control Elements:
    • Joystick or analog controls for fine-tuning robot movements.
    • Emergency Stop Button for safety during operation.

Communication and Connectivity:

  • Ethernet:
    • Supports Ethernet connections for real-time data exchange with the central automation system.
  • Fieldbus/Serial Protocols:
    • CANopen, EtherCAT, or PROFIBUS depending on system configuration for seamless communication with robot controllers and other system components.
  • USB Ports:
    • Allows for data transfer and the connection of external devices, like flash drives, for program updates or backups.
  • Wireless Connectivity:
    • Optional Wi-Fi or Bluetooth for wireless control and diagnostics, depending on the specific configuration.

Physical Characteristics:

  • Dimensions:
    • Compact and ergonomic design, typically around 200 mm x 150 mm x 40 mm.
  • Weight:
    • Typically in the range of 1.5 to 2.5 kg, ensuring portability and ease of use.
  • Enclosure Material:
    • Rugged, industrial-grade plastic or metal housing, designed to withstand the demands of industrial environments.
  • Mounting:
    • Handheld with an ergonomic grip for comfort during extended use.
  • Ingress Protection:
    • IP65 or higher for protection against dust and water ingress, making it suitable for harsh industrial conditions.

Power Supply:

  • Supply Voltage:
    • Typically 24V DC, in line with common industrial control systems.
  • Power Consumption:
    • Power consumption typically ranges from 5W to 15W depending on configuration and features in use.

Environmental Conditions:

  • Operating Temperature:
    • 0°C to 50°C, allowing for use in a variety of industrial environments.
  • Storage Temperature:
    • -20°C to 70°C to ensure functionality in harsh storage conditions.
  • Humidity:
    • 5% to 95% RH, non-condensing.
  • Vibration Resistance:
    • Meets industrial vibration standards to ensure continuous operation in high-vibration environments.

Safety Features:

  • Emergency Stop:
    • The pendant is equipped with a highly visible emergency stop button, allowing for quick shutdown in critical situations.
  • Fail-Safe Design:
    • The design includes fail-safe measures to prevent malfunctioning in case of communication loss or unexpected system errors.
  • CE, UL Certified:
    • The device meets all relevant safety standards, including CE and UL certifications for use in European and North American markets.

Key Features:

  1. High-Performance Display:

    • High-resolution TFT display for clear and easy monitoring of robot status and system diagnostics.

  2. Ergonomic and Rugged Design:

    • Handheld pendant with an ergonomic grip and robust construction, built to withstand tough industrial environments.

  3. User-Friendly Interface:

    • Touchscreen and physical buttons for intuitive robot control, along with emergency stop functionality for safety.

  4. Advanced Communication:

    • Supports Ethernet, CANopen, EtherCAT, and USB, allowing seamless integration with other industrial control systems and external devices.

  5. Wireless Capabilities:

    • Optional Wi-Fi or Bluetooth connectivity, enabling wireless control and diagnostics.

  6. Real-Time Control:

    • Provides real-time feedback and control over robotic systems, enhancing the flexibility and responsiveness of robot operations.

  7. Durability:

    • Built to endure harsh factory conditions with IP65-rated protection, ensuring protection from dust, water, and accidental contact.

Applications:

  1. Industrial Robotics:

    • Used for controlling and programming robotic systems in automated production lines, robotic arms, pick-and-place applications, and welding robots.

  2. Automated Assembly:

    • Perfect for robot-based assembly operations in industries like automotive manufacturing, electronics, and packaging.

  3. Machine Tending:

    • Machine tending robots in CNC machining, 3D printing, and injection molding systems benefit from this pendant for easy programming and operation.

  4. Flexible Manufacturing Systems (FMS):

    • Robotic systems controlled via this pendant are often part of flexible manufacturing systems, where robots need to be easily reprogrammed or reconfigured for different tasks.

  5. Laboratory Automation:

    • Used in laboratories for robotic handling of materials or samples in controlled environments, ensuring precise operations.

  6. Collaborative Robots (Cobots):

    • Operates in collaboration with humans, allowing for seamless integration in environments where safety and ease of use are paramount.

Conclusion:

The KEBA ERC 64/1-C Robot Pendant is a key device in the KEBA ecosystem, designed to provide a high-performance interface for controlling and programming robotic systems in industrial automation. With a rugged and ergonomic design, advanced communication protocols, and real-time control capabilities, it offers a reliable, user-friendly solution for robotic operators across various industries. Whether for robotic arms, automated production lines, or machine tending, this pendant ensures efficient and safe operations.

Let me know if you need additional details or have any questions regarding integration with other systems!
