KEBA KETop C40P/61955/04 Robot Handheld Instructor
⁦KEBA KETop C40P/61955/04 Robot Handheld Instructor⁩ - الصورة ⁦2⁩

KEBA KETop C40P/61955/04 Robot Handheld Instructor

  • Model: KEBA KETop C40P/61955/04
  • Type: Robot Handheld Instructor (HMI/PLC/Robot Controller)
  • Application: Control and monitoring of robotic systems in industrial automation environments.
  • Display Type: 7″ or larger color touchscreen for clear visual interaction with the robot’s functions.
  • Communication Interface: Supports Ethernet, Modbus, RS-232/RS-485, and other industrial communication protocols.
  • Industry Usage: Primarily used in robotics, automated manufacturing, assembly lines, material handling, and CNC operations.

Electrical Specifications:

  • Power Supply:

    • 24V DC for standard industrial power setups.
    • Power Consumption: Typically around 5W-15W depending on display brightness and connectivity.

  • Communication Interfaces:

    • Ethernet: For communication with PLCs and DCS systems.
    • Modbus RTU/TCP: For robotic controller communication and data exchange.
    • RS-232/RS-485: Serial communication for integration with robotic arms or machinery.

  • I/O Ports:

    • Digital Inputs: Several configurable digital I/O ports for interfacing with control signals from external systems.
    • Analog Inputs: Optional analog I/O for monitoring variables like force, temperature, or pressure in robotic systems.
احصل على عرض أسعار
التصنيف:

الوصف

Product Name:

KEBA KETop C40P/61955/04 Robot Handheld Instructor DCS/PLC Module

Product Description:

The KEBA KETop C40P/61955/04 is a Robot Handheld Instructor developed by KEBA, a leading company in industrial automation and HMI solutions. This module is specifically designed for intuitive, flexible, and ergonomic control of robotic systems within industrial environments. The KETop C40P is part of KEBA’s HMI (Human-Machine Interface) family and is designed for use in complex automation systems, enabling operators to control and monitor robots in real-time, whether they are in an industrial assembly line, robotic arms in manufacturing processes, or automated material handling systems.

Equipped with a high-resolution touch display and offering integrated functionalities for controlling robotic movements, the KETop C40P/61955/04 enhances operational efficiency through its intuitive user interface. It also supports seamless integration with DCS (Distributed Control System) and PLC (Programmable Logic Controller) systems, making it an ideal solution for advanced robotic applications that require real-time feedback and control.

This handheld device is designed with a focus on providing users with both operational flexibility and safety. The ergonomic design ensures that operators can control robotic movements with ease, while the embedded communication interfaces allow for smooth integration into larger automation systems.

Product Parameters & Specifications:

General Specifications:

  • Model: KEBA KETop C40P/61955/04
  • Type: Robot Handheld Instructor (HMI/PLC/Robot Controller)
  • Application: Control and monitoring of robotic systems in industrial automation environments.
  • Display Type: 7″ or larger color touchscreen for clear visual interaction with the robot’s functions.
  • Communication Interface: Supports Ethernet, Modbus, RS-232/RS-485, and other industrial communication protocols.
  • Industry Usage: Primarily used in robotics, automated manufacturing, assembly lines, material handling, and CNC operations.

Electrical Specifications:

  • Power Supply:

    • 24V DC for standard industrial power setups.
    • Power Consumption: Typically around 5W-15W depending on display brightness and connectivity.

  • Communication Interfaces:

    • Ethernet: For communication with PLCs and DCS systems.
    • Modbus RTU/TCP: For robotic controller communication and data exchange.
    • RS-232/RS-485: Serial communication for integration with robotic arms or machinery.

  • I/O Ports:

    • Digital Inputs: Several configurable digital I/O ports for interfacing with control signals from external systems.
    • Analog Inputs: Optional analog I/O for monitoring variables like force, temperature, or pressure in robotic systems.

Mechanical Specifications:

  • Display:

    • 7″ to 10″ TFT color touchscreen, with multi-touch capabilities.
    • Resolution: 1024 x 600 or higher for a sharp, clear interface.

  • Dimensions:

    • Approximate size: 250mm x 180mm x 75mm (varies based on model and configuration).

  • Weight:

    • Lightweight for ease of handheld operation: Approx. 1.5 kg (3.3 lbs).

  • Mounting:

    • Ergonomic Handle for comfortable handheld use.
    • Option to mount on a fixed stand or arm for hands-free operation.

  • Enclosure:

    • IP65 rated, dust-tight and water-resistant for protection in harsh industrial environments.

Environmental Specifications:

  • Operating Temperature:

    • -10°C to +50°C, designed for a wide range of industrial environments.

  • Storage Temperature:

    • -20°C to +60°C, ensuring safe storage even in extreme conditions.

  • Humidity:

    • 5% to 95% RH, non-condensing for operation in humid environments.

  • Vibration Resistance:

    • Meets IEC 60068-2-6 standards for vibration resistance, suitable for industrial machinery and robotics.

  • Shock Resistance:

    • Withstands up to 50g shock (half-sine), designed for durability in industrial settings.

Safety & Protection Features:

  • Safety:

    • Emergency stop button and safety lockout mechanisms for quick shutdown in critical situations.

  • Overvoltage Protection:

    • Integrated to prevent damage from electrical surges.

  • Overcurrent Protection:

    • Automatically detects and mitigates potential overcurrent scenarios, ensuring safe operation.

Display and User Interface:

  • Touchscreen Interface:

    • High-resolution capacitive touchscreen that allows operators to monitor real-time data, adjust robot paths, and change settings.

  • Multi-touch Functionality:

    • Supports pinch-to-zoom, swipe, and other intuitive gestures for enhanced usability.

  • Ergonomic Design:

    • Handheld form factor with an ergonomic grip for extended use without causing hand fatigue.

  • Customizable User Interface:

    • User-defined control screens for easy robot operation, with customizable buttons and layouts to suit specific applications.

  • Haptic Feedback:

    • Provides tactile feedback for an enhanced operator experience during control.

Software Features:

  • Control & Monitoring:

    • Allows operators to directly control robotic movements, monitor performance, and adjust parameters in real time.

  • Pre-programmed Motion Paths:

    • Supports the use of pre-configured motion paths for routine tasks, with the ability to modify and customize paths.

  • Remote Diagnostics:

    • Includes remote diagnostics capabilities for fault detection and maintenance planning.

  • Real-time Data Logging:

    • Logs robot activity, performance data, and error logs for later analysis or troubleshooting.

  • Integration with Automation Systems:

    • Seamlessly integrates with various DCS and PLC systems, supporting various protocols like Ethernet/IP, Modbus, and PROFINET.

Certifications & Compliance:

  • Certifications:

    • CE, UL, and RoHS compliant.

  • EMC Compliance:

    • Conforms to EN 61000-6-2 for immunity and EN 61000-6-4 for emissions in industrial environments.

  • Safety Standards:

    • Meets ISO 13849-1 for safety of machinery and IEC 61508 for functional safety in control systems.

Key Features:

  1. Ergonomic Handheld Design:

    • Lightweight, ergonomic form factor for comfortable long-term use.

  2. Intuitive Touchscreen Interface:

    • High-resolution color display with multi-touch support for ease of interaction.

  3. Advanced Communication Protocols:

    • Ethernet, Modbus, RS-232/RS-485 support for seamless integration with robots, PLCs, and DCS systems.

  4. Customizable Control Screen:

    • Personalized user interface with buttons and layouts tailored to specific robot applications.

  5. Real-time Monitoring and Control:

    • Operators can control robotic movements, view real-time status, and access diagnostics.

  6. Safety Features:

    • Integrated emergency stop button and safety mechanisms for high-risk environments.

  7. Rugged Design:

    • IP65-rated, resistant to dust, water, and industrial vibrations/shocks.

  8. Remote Access and Diagnostics:

    • Enables off-site diagnostics and performance analysis for predictive maintenance.

Applications:

  • Robot Programming and Control:

    • Ideal for use in robotic assembly lines, CNC operations, and automated material handling.

  • Robotics Research & Development:

    • Used in R&D environments for testing, programming, and troubleshooting robotic systems.

  • Automated Manufacturing:

    • Widely used in automated factories for direct control and operation of robots performing tasks like assembly, painting, and welding.

  • Maintenance & Diagnostics:

    • Provides diagnostic capabilities for monitoring robotic health and performance in real-time, improving uptime and operational efficiency.

Conclusion:

The KEBA KETop C40P/61955/04 Robot Handheld Instructor DCS/PLC Module offers a powerful, ergonomic, and highly integrated solution for controlling and monitoring industrial robots. With its high-resolution touchscreen, advanced communication protocols, and ergonomic design, it provides users with an intuitive interface for precise robotic control. Whether used in robot programming, automated manufacturing, or maintenance diagnostics, this device enhances the efficiency and safety of robotic operations in various industries, from automotive to electronics.
