PROSOFT PLX32-EIP-SIE DCS PLC Module

Product Name:

PROSOFT PLX32-EIP-SIE DCS PLC Module

Product Description:

The PROSOFT PLX32-EIP-SIE is an industrial communication module designed for seamlessly integrating devices into Ethernet/IP networks, enabling communication between programmable logic controllers (PLCs), remote I/O devices, and other automation equipment. It provides Ethernet/IP communication capabilities for systems requiring fast and reliable data transfer in real-time applications. The PLX32-EIP-SIE is specifically engineered for industries where high-speed data exchange is essential, such as process automation, industrial control, and distributed control systems (DCS).

This module is an essential component in industrial environments where it is necessary to establish communication between devices that support the Ethernet/IP protocol. With the PLX32-EIP-SIE, users can connect their existing automation equipment to an Ethernet network for enhanced monitoring, control, and diagnostics. The module supports advanced features like I/O and device fault diagnostics, automatic device discovery, and easy configuration, making it ideal for use in complex automation systems.

Key Features:

• Ethernet/IP Communication: Enables high-speed communication between devices over Ethernet/IP networks.
• Modular Design: Compact and flexible, making it easy to integrate into existing PLC systems and DCS applications.
• Real-time Data Transfer: Provides real-time, deterministic data exchange between devices in distributed control systems.
• Diagnostics and Monitoring: Includes diagnostic tools to track system health and troubleshoot communication issues.
• Automatic Device Discovery: Simplifies the process of identifying and configuring devices connected to the network.
• Plug-and-Play: Easy installation with minimal setup required for basic functionality.
• Supports Multiple I/O Devices: Can be integrated with a variety of I/O modules to support a wide range of automation and control needs.

Product Parameters:

• Model: PLX32-EIP-SIE
• Manufacturer: ProSoft Technology
• Type: Ethernet/IP Communication Module
• Form Factor: Industrial modular design for easy integration
• Connectivity: Supports Ethernet/IP communication with both standard and extended I/O devices
• Power Supply: Typically powered via the 24V DC power source from the PLC or automation system
• Operating System Support: Compatible with multiple operating systems used in industrial control systems

Product Specifications:

1. Communication Protocols:

   • Ethernet/IP: Supports full Ethernet/IP (CIP) protocol for industrial automation, including control and data exchange.
   • TCP/IP: Standard communication over TCP/IP network for fast data transfer.
   • UDP: User Datagram Protocol support for time-sensitive communication.
   • Dynamically Assigned IP: Supports DHCP (Dynamic Host Configuration Protocol) for automatic IP address assignment in networks.

2. I/O Support:

   • I/O Modules: Compatible with a wide range of I/O devices, including analog, digital, and specialty modules.
   • I/O Configuration: Supports configuration of both discrete and analog I/O devices, ensuring flexible integration into existing systems.

3. Network Connectivity:

   • Ethernet Ports: 1 x 10/100Base-T Ethernet port for network communication.
   • Auto-negotiation: Supports automatic detection of network speed (10/100Mbps) for compatibility with various network infrastructures.

4. Power Supply:

   • Voltage Range: 24V DC nominal power input, with a wide operating voltage range of 20-28V DC.
   • Power Consumption: Typically 1W – 3W depending on configuration and connected devices.

5. Diagnostics and Monitoring:

   • LED Indicators: Provides status indicators for network activity, power status, and fault conditions (e.g., I/O, communication).
   • Diagnostic Tools: Built-in diagnostics to detect communication issues, device faults, and provide detailed error messages.
   • Fault Logging: Capable of logging faults for post-event analysis and troubleshooting.

6. Dimensions and Form Factor:

   • Dimensions: Approximately 4.5” (W) x 3” (L) x 1” (H) (depending on configuration)
   • Weight: Approximately 0.3 kg (varies depending on specific configuration)
   • Mounting: DIN rail or panel-mount options for easy installation.

7. Performance:

   • Data Rate: 100 Mbps for Ethernet communication (supports both 10 Mbps and 100 Mbps Ethernet networks).
   • Real-time Data Exchange: Supports time-sensitive applications with low latency and deterministic data transfer.
   • Connection Management: Supports up to 128 I/O connections simultaneously.

8. Environmental Conditions:

   • Operating Temperature: Typically -20°C to +70°C (depending on specific model and configuration)
   • Storage Temperature: -40°C to +85°C
   • Humidity: 5% to 95% (non-condensing)
   • Vibration Resistance: Suitable for industrial environments with typical vibration levels.
   • Shock Resistance: Designed to withstand common industrial shock levels.

9. Compliance and Certifications:

   • CE: Compliant with European Union directives for safety and electromagnetic compatibility.
   • UL: Certified for North American safety standards (UL Listed).
   • RoHS: Compliant with the Restriction of Hazardous Substances (RoHS) directive for environmental safety.

10. Mounting and Installation:

    • DIN Rail Mounting: Easy installation in control panels and automation enclosures.
    • Panel Mounting: Optional panel mounting for compact and integrated installations.

11. Configuration and Software:

    • ProSoft Configuration Tool: Software tool for easy configuration of the module, enabling users to quickly set up communication parameters, I/O mapping, and network settings.
    • Device Integration: Supports integration into various industrial control systems and DCS applications using Ethernet/IP.

Applications:

The PROSOFT PLX32-EIP-SIE DCS PLC module is ideal for use in various industrial automation and control applications, including:

• Process Automation: Enables Ethernet/IP connectivity for real-time process monitoring and control.
• Factory Automation: Used in applications that require flexible communication with PLCs, I/O devices, and field instruments.
• Industrial Networking: Facilitates communication between Ethernet-enabled devices, including remote I/O, sensors, and actuators.
• Distributed Control Systems (DCS): Enables integration of distributed control systems, facilitating seamless communication between devices over Ethernet/IP.
• Energy and Utilities: Used in power generation, oil and gas, and other critical infrastructure for reliable communication.

Additional Features:

• Quick Installation and Setup: The PLX32-EIP-SIE is designed for quick and easy integration into existing systems with minimal setup required.
• Advanced Diagnostics: Features like error tracking, event logging, and health monitoring ensure system stability and proactive maintenance.
• Scalable and Modular: Supports easy expansion as the needs of the automation system grow.
• Plug-and-Play Operation: No complex configuration required for most basic network connections.

The PROSOFT PLX32-EIP-SIE module is an essential tool for enabling Ethernet/IP communication in industrial control systems, offering robust performance, advanced diagnostic features, and seamless integration into modern automation networks.
