Triconex 9101-010

الوصف

The Triconex 9101-010 is not a module or a standard termination panel, but a specialized fanned-out cable used in Triconex safety instrumented systems. Its purpose is to provide a direct, labeled connection between a Triconex I/O module and a third-party termination block or custom wiring solution.

What It Does

Think of the 9101-010 as a flexible wiring alternative for situations where a standard, pre-built termination panel isn’t the best fit. It’s a 56-pin cable with a connector on one end that plugs directly into a Triconex I/O module. On the other end, the individual wires are “fanned-out,” meaning they are separated, stripped, tinned, and clearly labeled. This allows you to wire the signals directly to your own terminal strips or custom-built hardware.

This cable is most useful for system integrators or engineers who need to connect Triconex modules to an existing cabinet layout, or when they want to use a specific type of terminal block that isn’t offered by Triconex.

Key Features and Compatibility

The 9101-010 is designed for flexibility and ease of use.

• Functionality: It provides a direct, point-to-point connection, eliminating the need for a standard Triconex termination panel.
• Compatibility: This cable works with a variety of Triconex I/O modules, particularly those with a 56-pin connector. It’s commonly used with the 3623 and 3624 supervised digital output modules. It can also be used with 32-point input modules where two cables or a combination of a cable and a panel might be needed to terminate all points.
• Leads: The cable has 50 individual, 22-gauge leads that are clearly labeled. This makes wiring organized and helps reduce the chance of errors during installation.

Technical Specifications
