WOODWARD 8262-3183

الوصف

The WOODWARD 8262-3183 is identified as a specific configuration within a Standard MicroNet+ Kit. This means it’s not a single, standalone module like a simple input or output card, but rather a pre-assembled package or a key component part of a larger, integrated control system provided by Woodward.

1. SEO-Optimized Titles

• WOODWARD 8262-3183: Standard MicroNet+ Kit, 8-Slot, 2 x 120 V AC/DC PS, Relay Drivers, Analog Combo.
• WOODWARD 8262-3183: MicroNet+ Integrated Control System Kit.
• WOODWARD 8262-3183: Woodward Turbine & Engine Control Hardware Package.
• WOODWARD 8262-3183: Industrial Control System with Mixed I/O and Redundant Power.

2. Product Overview

The WOODWARD 8262-3183 denotes a specific Standard MicroNet+ Kit configuration. These kits are comprehensive solutions designed to provide the core hardware for controlling prime movers (like gas turbines, steam turbines, or engines) and associated processes. This particular kit is characterized by:

• 8-Slot Chassis: Indicates the physical enclosure that houses the control modules.
• 2 x 120 V AC/DC Power Supplies (PS): Suggests redundant power for enhanced reliability and flexibility in power input.
• Relay Drivers: Implies the presence of discrete outputs capable of directly driving external relays.
• Analog Combo Module: Indicates inclusion of a module handling both analog input and analog output signals.

This combination makes it a versatile kit for applications requiring both discrete (on/off) and analog (continuous) control capabilities with a focus on reliability through redundant power.

• Product Type: Standard MicroNet+ Hardware Kit Configuration
• Manufacturer: Woodward
• Series: MicroNet+ Digital Control Systems
• Key Components: 8-slot chassis, redundant 120 V AC/DC power supplies, relay drivers (discrete outputs), and an analog combination module.
• Function: Provides the foundational hardware for a robust industrial control system, capable of managing complex turbine, engine, or process control applications.

3. Detailed Product Description

Woodward’s MicroNet+ is a highly capable and flexible digital control platform renowned for its use in critical industrial applications such as power generation, oil & gas, and industrial processes. The 8262-3183 is one of several pre-configured “Standard MicroNet+ Kits” that Woodward offers to simplify the deployment and integration of these powerful control systems.

This specific kit, the 8262-3183, is designed to provide a comprehensive set of capabilities:

• Chassis and Power Supplies: It includes an 8-slot chassis, which serves as the backplane and housing for various MicroNet+ I/O and processor modules. The inclusion of two 120 V AC/DC power supplies is a significant feature, providing power redundancy. This means if one power supply fails, the other can continue to power the system, greatly increasing reliability and uptime in critical applications. The AC/DC compatibility offers flexibility in plant power infrastructure.
• I/O Capabilities (Relay Drivers & Analog Combo):
  • Relay Drivers: This indicates that the kit likely includes or is configured for discrete output modules that can directly drive external relays. These are used for on/off control of various plant equipment, such as starting/stopping pumps, activating solenoid valves, or controlling alarms.
  • Analog Combo Module: This implies the presence of an Analog Input/Output (AIO) module that can handle both continuous input signals (e.g., 4-20 mA from pressure/flow sensors) and continuous output signals (e.g., 4-20 mA to proportional control valves). This combination provides versatile analog control and monitoring capabilities.
• System Integration: As a MicroNet+ kit, it’s designed to integrate seamlessly with other Woodward modules, including various processors (CPUs) and additional I/O cards (e.g., speed inputs, RTD/thermocouple inputs) to form a complete control solution.
• Programming: The entire MicroNet+ system, including the functionality enabled by this kit, is custom-programmable using Woodward’s Graphical Application Program (GAP™) software. This allows engineers to develop complex control logic, sequencing, protection schemes, and performance optimization algorithms tailored to specific machinery or processes.
• Robustness and Reliability: MicroNet+ systems are built to withstand harsh industrial environments. They can be configured for simplex, redundant, or even Triple Modular Redundant (TMR) architectures for applications demanding the highest levels of availability and safety, though this specific kit is classified as “Standard,” often implying a simplex or a basic redundant setup for the core components.

In essence, the 8262-3183 kit provides a foundational, versatile, and reliable hardware base for implementing advanced control strategies in industrial prime mover and process control applications.

4. Technical Specifications (General)

As a kit, detailed specifications apply to the included components. However, based on the description:

5. Typical Applications

The WOODWARD 8262-3183 kit is ideally suited for a wide range of critical industrial applications where reliable and flexible control of prime movers and associated processes is required:

• Gas Turbine Control: Comprehensive control from start-up through various operating states (acceleration, loading/unloading, steady-state) to safe shutdown. This includes fuel metering, speed control, temperature management (EGT), vibration monitoring, and safety interlocks.
• Steam Turbine Control: Governing speed, load, extraction/admission pressures, and other process parameters.
• Industrial Engine Control: Managing speed, fuel delivery, and protection for various industrial engine applications.
• Compressor Control: Implementing anti-surge control, load sharing, and station control for large industrial compressors.
• Power Generation: Providing the core control for generators and their auxiliary systems.
• Mechanical Drive Systems: Used for precise control in applications where a prime mover drives mechanical equipment like pumps or fans.
