Woodward 8446-1059

الوصف

The Woodward 8446-1059 is a remote control and annunciation panel, specifically designed as a variant of the RP-3000 series. Its primary purpose is to serve as a Human-Machine Interface (HMI) for Woodward’s easYgen-3000 series of genset controllers, particularly in applications where the main controller is not mounted on the front of a panel.

Key Features and Applications

This panel is essential for providing a user-friendly interface for operators who need to control and monitor a generator system from a distance. It’s especially useful when the easYgen controller itself is mounted on the back of a cabinet, in a separate location, or as part of a larger control system.

• Remote HMI: The 8446-1059 allows for remote visualization, control, and configuration of a compatible easYgen-3000 series genset controller. It essentially mirrors the functions of a front-panel-mounted easYgen unit, providing access to menus, system status, and control actions.
• Compatibility: This specific part number is designed to support the easYgen-3400-P1 Rental model. This is a crucial distinction, as different RP-3000 panels are configured to work with specific easYgen controller models and packages.
• Intuitive Interface: The panel features an LCD with a keypad, making it easy to navigate through menus, view system statuses, and perform control actions without needing to open the main control cabinet.
• Enhanced Safety: The panel includes an emergency stop function for critical situations, providing an additional layer of safety.
• Robust Design: The unit is built for demanding industrial and marine environments, with resistance to vibration and shock, and a wide operating temperature range.

Technical Specifications
