The WOODWARD 8923-2276 refers to a Transient Voltage Kit for 12 V systems.

WOODWARD 8923-2276: 12V Transient Voltage Kit

The WOODWARD 8923-2276 is a protective accessory designed to safeguard sensitive electronic equipment, particularly in industrial or marine environments where voltage spikes and fluctuations are common. It’s a component that enhances the reliability and longevity of control systems by mitigating transient voltage events.

Product Overview

This part number is part of a series of transient voltage protection kits offered by Woodward. These kits are essential for maintaining stable operation of electronic controls, especially in applications where the power supply may not be perfectly stable.

• Product Type: Transient Voltage Kit
• Manufacturer: Woodward
• Part Number: 8923-2276
• Voltage Rating: Designed for 12 V systems. This indicates it’s specifically configured to protect devices operating on a 12-volt DC power supply.
• Function: Absorbs or diverts harmful voltage spikes (transients) that can occur due to events like lightning strikes, inductive load switching, or other electrical disturbances, preventing them from reaching and damaging sensitive electronic components within control systems.
• Benefit: Increases the robustness and reliability of electronic controls, reduces maintenance costs, and minimizes downtime caused by electrical overstress.

Detailed Product Description

Transient voltage kits like the Woodward 8923-2276 are crucial for protecting industrial and marine electronic equipment. While a detailed public datasheet for this specific kit (like a circuit diagram) isn’t typically available, its purpose is universally understood in electrical protection.

• Protection Mechanism: Such kits typically use components like metal oxide varistors (MOVs), transient voltage suppressor (TVS) diodes, or other surge suppression technologies. These components are designed to “clamp” or short-circuit excessive voltages, diverting the energy away from the protected equipment when a voltage spike occurs.
• Application Environment: Given Woodward’s focus, these kits are commonly used in conjunction with their governors, actuators, and other control modules found in power generation, marine propulsion, and industrial process control. These environments often have significant electrical noise and potential for transients.
• Installation: The kit would typically be installed in line with the power supply to the electronic device it’s protecting, or possibly integrated directly into the wiring harness. Proper grounding is essential for its effective operation.

Technical Specifications (General for 12V Transient Voltage Kits)

Typical Applications

The WOODWARD 8923-2276 Transient Voltage Kit is used in any application where 12 VDC electronic controls need protection from electrical noise and damaging voltage transients. This often includes:

• Engine Control Systems: Protecting electronic governors, fuel system controllers, and ignition modules on 12V diesel or gas engines.
• Marine Applications: Safeguarding navigation electronics, engine control units, and other sensitive electrical systems on boats and ships.
• Generator Control Panels: Protecting controller modules and associated electronics in generator sets.
• Industrial Automation: Where 12V sensors, PLCs, or other control devices are susceptible to power quality issues.
